1.8 Disposal

Device may only be disposed in a professional manner!
The disposal of devices and components may only be realised in accordance with good professional practice observing the
country-specifi c regulations. Incorrect disposal can cause environmental risks.

1.9 Return

All devices delivered to Camille Bauer Metrawatt AG shall be free of any hazardous contaminants (acids, lyes, solutions, etc.).
Use original packaging or suitable transport packaging to return the device.
Damage by returning
Damages caused by improper returning, no warranties or guarantees can be given.

2. Introduction

2.1 Purpose of this document

This document describes the current transformer SIRAX BT7000 and BT7050. It is intended to be used by Installation personnel, commissioning
engineers, Service and maintenance personnel.
Scope
This handbook is valid for all versions of the current transformer SIRAX BT7000 and BT7050. Some of the functions described in this document
are available only, if the necessary optional components are included in the device.
Required knowledge
A general knowledge in the field of electrical engineering is required. For assembly and installation of the device knowledge of applicable national
safety regulations and installation standard is required.

2.2 Scope of supply

Current transformer SIRAX BT7000 or BT7050 with Connection set
•
Safety instructions (ge, en, fr, it, es, nl, cz)
•

2.3 Further documents

The following documents are provided electronically via www.camillebauer.com:
Datasheet (ge, en)
•
Safety instructions (ge, en, fr, it, es, nl, cz)
•
Operating manual (ge, en)
•
Flyer current transformer program
•

3. Functional description

The SIRAX BT7000 and BT7050 are current transformers for monitoring 1-phase AC and DC systems up to a maximum current of 50 A. The
current measurement is galvanically separated from the measured line. The devices are the ideal solution for applications where power needs to be
monitored. They are perfect for monitoring medium / large photovoltaic systems, battery charging systems and industrial processes.

4. Assembly and installation

Ensure a safe working environment during assembly, installation and maintenance work. Disconnect the power supply of the
primary conductor and secure it against unintentional reconnection.
Magnetic fields of high intensity can vary the values measured by the transformer. Avoid installation near permanent magnets,
electromagnets or iron masses that induce strong changes in the magnetic field. If there are any irregularities, we recommend
realigning or moving the transformer in the most appropriate area.
• Mounting is via screw grooves for vertical and horizontal panel mounting or via fastening elements for vertical and horizontal DIN rail moun-
ting.
• The installation of the devices is arbitrary.
• Now connect the device according to the wiring diagram.
PM 1001931 000 00 Current transformer for AC and DC SIRAX BT7000/BT7050 15/24
