Specifications; Important Safety Information - Performance Tool W41062 Owner's Manual

12 ton hydraulic shop press
Table of Contents

Advertisement

SPECIFICATIONS

Max. Capacity: ............................ 24,000 lbs.
Working Range: .......................... 0 to 35-3/4 in. (0-910 mm)
Stroke: ......................................... 7 in. (180 mm)
Bed Width: ................................... 20 in. (510 mm)

IMPORTANT SAFETY INFORMATION

Read all safety warnings before operation.
WARNING!
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFETY INSTRUCTIONS
AND WARNINGS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE
FOR WHICH IT IS INTENDED. FALURE TO DO SO MAY CAUSE DAMAGE TO PROPERTY
AND/OR SERIOUS PERSONAL INJURY. PLEASE KEEP THIS INSTRUCTION MANUAL
SAFE FOR FUTURE USE.
1. Use a qualified person to maintain the press in good condition. Keep it clean for best and safest performance.
2. The maximum load is 12 tons. DO NOT exceed this rated capacity. Never apply excessive force to a workpiece and
always use the pressure gauge to accurately determine the applied load.
3. Use this press for the purpose for which it is intended. DO NOT use it for any other purpose it is not designed to
perform.
4. Keep children and unauthorized persons away from the work area.
5. Remove ill fitting clothing. Remove ties, watches, rings and other loose jewelry, and contain long hair.
6. Wear ANSI approved impact safety goggles, full-face impact safety shield and heavy-duty work gloves when operating
the press.
7. Keep proper balance and footing, do not overreach and wear nonskid footwear.
8. Only use this press on a surface that is stable, level, dry and not slippery, and capable of sustaining the load. Keep the
surface clean, tidy and free from unrelated materials and ensure that there is adequate lighting.
9. Inspect the press before each use. DO NOT use if bent, broken, cracked, leaking or otherwise damaged, any suspect
parts are noted or it has been subjected to a shock load.
10. Check to ensure that all applicable bolts and nuts are firmly tightened.
11. Ensure that workpiece is center-loaded and secure.
12. Keep hands and feet away from bed area at all times.
13. DO NOT use the shop press to compress spring or any other item that could disengage and cause a potential hazard.
Never stand directly in front of loaded press and never leave loaded press unattended.
14. DO NOT operate the press when you are tired or under the influence of alcohol, drugs or any intoxicating medication.
15. DO NOT allow untrained persons to operate the press.
16. DO NOT make any modifications to the press.
17. DO NOT use brake fluid or any other improper fluid and avoid mixing different types of oil when adding hydraulic oil.
Only good quality hydraulic jack oil can be used.
18. DO NOT expose the press to rain or any other kind of bad weather.
19. If the press needs repairing and/or there is any part that needs to be replaced, have it repaired by authorized
technicians and only use the replacement parts supplied by the manufacturer.
20. WARNING: the warnings, cautions and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be supplied by the operator.
2
Specifications are subject to change
without notice
