- Page 1 12 Ton HYDRAULIC SHOP PRESS Stock Number W41062 OWNER’S MANUAL FOR YOUR SAFETY, please read these instructions carefully and retain them for future use.
-
Page 2: Specifications
SPECIFICATIONS Max. Capacity: ......24,000 lbs. Working Range: ......0 to 35-3/4 in. (0-910 mm) Specifications are subject to change Stroke: ......... 7 in. (180 mm) without notice Bed Width: ........20 in. (510 mm) IMPORTANT SAFETY INFORMATION Read all safety warnings before operation. WARNING! PLEASE READ THESE INSTRUCTIONS CAREFULLY. - Page 3 ASSEMBLY INSTRUCTIONS Use the exploded drawing as your guide to assemble. Lay all parts and assemblies out in front of you before beginning. The following procedure is recommended: 1. Attach one base section to left post, add the support straps to the base and post.
-
Page 4: Before First Use
BEFORE FIRST USE 1. Note: Before first use of this product, purge away air from the hydraulic system: open the release valve by turning it coun- terclockwise. Pump several full strokes to eliminate any air in the system. 2. Check all parts and conditions, if there is any part broken, stop using it and contact your supplier immediately. OPERATING INSTRUCTIONS WARNING! Ensure that you read, understand and apply the safety instructions and warnings before use. - Page 5 15 14 13 15 14 13...
- Page 6 RAM PARTS LIST Part No. Description Qty. Retaining ring Sealing ring Ring O-ring Circlip Piston washer Screw M8 Spring R10 Seal bolt R11 Gauge coupler R12 Gauge connection nut R13 pin R14 Gauge coupler R15 Gauge connection nut R16 O-ring R17 Dust cap R18 Coupler R19 Ring...
- Page 7 90 days from the date of purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective and under warranty.
