SmartLPR
®
Access User Manual
Please follow the indications and note you don't need to open the unit in order to install
and configure it and be aware that the warranty will be immediately voided if the unit
presents signs of manipulations applied in the attempt to open it.
1.3.
Operating Modes
The main purpose of SmartLPR
of the vehicles traveling in the lanes controlled.
The system has different operating modes as follows:
1. Software Trigger: the client application notifies SmartLPR
presence. The vehicle image is automatically captured and processed. The results obtained are
sent back to the client application.
2. Hardware Trigger: SmartLPR
beneath the tarmac, a vehicle presence signal and notifies the client application. Then, the
vehicle image is captured and processed. The results obtained are sent back to the client
application. When the vehicle leaves the lane, the client application is once again notified.
Special cases:
3. Pre-trigger: SmartLPR
approaching and internally stores the best recognition obtained. When the client application
request the license plate, the unit immediately sends it.
Installation scenarios:
●
This operating mode should be used for those particular cases when the installation
●
has physical constraints and therefore it is mandatory to place the unit
immediately before or after the barrier or when the camera needs to be
embedded in the barrier.
However, we recommend using the software or hardware trigger mode whenever
●
possible.
As this mode works continuously, it is not possible to use it with color plate
●
recognition models (due to the fact they use white light) nor with WL (high
resolution) units.
Quercus Technologies
®
Access is to provide to the client applicationthe license plates
®
Access receives directly from a sensor, installed
®
Access continually recognizes license plates as vehicles are
Basic concepts
®
Access of detecting vehicle
9
