OWNER'S MANUAL
LG Digital
Signage
(LED SIGNAGE)
Please read the safety information carefully before using this product.
After reading this manual, keep it in an easily accessible location for future reference.
LAT240DT1
LAT240DT2
ACC-LATB2
ACC-LATB3
www.lg.com
LCLG012U
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
Advertisement
Table of Contents
Related Manuals for LG LAT240DT1
Summary of Contents for LG LAT240DT1
- Page 1 (LED SIGNAGE) Please read the safety information carefully before using this product. After reading this manual, keep it in an easily accessible location for future reference. LAT240DT1 LAT240DT2 ACC-LATB2 ACC-LATB3 www.lg.com LCLG012U Copyright © 2018 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS .....3 - Electrical Power Related Precautions ....3 - Precautions for installing the Product..... 5 - Precautions for Moving the Product ....6 - Precautions for Using/Cleaning the Product 7 - Product Disposal (Only, Hg lamp used LCD Monitor) ................ -
Page 3: Safety Precautions
WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. SAFETY PRECAUTIONS Please read these safety precautions carefully before using the product. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death. CAUTION If you ignore the caution message, you may be slightly injured or the product may be damaged. - Page 4 If you don’t intend to use the product for a long time, unplug the power cable from the product. • - Layers of dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire. Insert the power plug firm so it cannot come loose. •...
-
Page 5: Precautions For Installing The Product
- Dust or moisture can cause electrical shock, fire or product damage. Do not add accessories that have not been designed for this display. • If you smell smoke or other odors or hear a strange sound from the product unplug the power cord and contact LG • Customer Service. -
Page 6: Precautions For Moving The Product
Precautions for Moving the Product WARNING Make sure to turn off the product. • - You may be electrocuted or the product can be damaged. Make sure to remove all cables before moving the product. • - You may be electrocuted or the product can be damaged. When lifting or moving the product, do not hold it upside down while holding only the stand. -
Page 7: Precautions For Using/Cleaning The Product
Do not attempt to disassemble, repair or modify the product yourself. • - Fire or electric shock can occur. - Contact LG Customer Service for repair. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching. Do not •... -
Page 8: Assembling And Preparing
ASSEMBLING AND PREPARING CAUTION Always use genuine components to ensure safety and product performance. • The product warranty will not cover damage or injury caused by the use of counterfeit components. • Connect the power cord to the product before you plug it into a wall outlet. Plugging the power cord into a wall •... -
Page 9: Remote Control Receiver
WARNING The warranty will not cover any component damage caused by electrostatic discharge at the time of installation. • When installing this product, you must wear anti-electrostatic discharge (ESD) gear. There should be no oil, water, dust and foreign substance on the glass surface where the colored, transparent LED •... -
Page 10: Optional Accessories
Optional Accessories Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and optional accessories. LCLG002 ACC-LATP1 NOTE Optional accessories are only available for some models. -
Page 11: Parts
Parts The illustrations may differ depending on the model. LAT240DT1 LAT240DT2 ACC-LATB2 ACC-LATB3... - Page 12 LCLG012U...
-
Page 13: Installing On A Wall
Installing on a Wall Fix the assembled set on a desired place. LCLG012U 283 mm (11.1 inches) 139 mm (5.4 inches) -
Page 14: Troubleshooting
TROUBLESHOOTING No image is displayed or the screen image looks abnormal. Problem Solution Is the power cord connected to the Check if the power cord is correctly plugged into the power outlet. • product? Check if the cable is properly connected. Problems may occur if the user connects cables arbitrarily. -
Page 15: Product Specifications
PRODUCT SPECIFICATIONS Without prior notice, all product information and specifications contained in this manual are subject to change to improve the performance of the product. symbol means alternating current, and the symbol means direct current. Film Panel Screen Type Film Panel Usage Condition Daily Usage Time 24 hours (video) - Page 16 24 mm (H) X 24 mm (V) Film Panel Pixel pitch On Mode: 25 W (Typ.) Power Power Consumption LAT240DT1 668 X 480 X 1.8 (mm) / 0.73 (kg) Dimensions (Width x Height x Depth) / (26.2 X 18.8 X 0.07 (inches) / 1.6 (lbs)) Weight LAT240DT2 475 X 480 X 1.8 (mm) / 0.52 (kg)
- Page 17 [Unit: mm (inches)] 668 (26.2) (18.8) LAT240DT1 (0.07) 475 (18.7) (18.8) LAT240DT2 (0.07)
- Page 18 [Unit: mm (inches)] 293 (11.5) 188.7 (7.4) (1.4) LCLG012U 547.3 (21.5) 63 (2.4) ACC-LATB2 479.5 (18.8) 28.1 (1.1) ACC-LATB3 (0.9)
- Page 19 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 1000 Sylvan Ave Englewood Cliffs, NJ 07632 Telephone (201)266-2215 The label attached to the product contains information you need to receive service. Note for user/reseller: The noise that occurs temporarily...
