- Page 1 GEBRUIKSAANWIJZING MODE D’EMPLOI OPERATING INSTRUCTIONS WARMTE RECUPERATOR TYPE INSERT RECUPERATEUR DE CHALEUR TYPE INSERT HEATING APPLIANCE INSERT TYPE MODEL SORDO 60 475.6311.100 SORDO 70 475.7311.100 SORDO 80 475.8311.100 SORDO 80 Flatline 475.8209.100 www.saeyheating.com xxx.xxx.xxx...
-
Page 2: Table Of Contents
READ THESE OPERATING INSTRUCTIONS CAREFULLY BEFORE USING THE APPLIANCE OPERATING INSTRUCTIONS INSERT STOVE TYPE WOOD CASSETTE MODEL Sordo 60 – 70 – 80 and 80 flatline Page INDEX 1. GENERAL 2. TECHNICAL CHARACTERISTICS 3. FUEL: WOOD 4. DE FLUE 5. COMBUSTION AIR 6. -
Page 3: General
1 GENERAL: Dear user, In purchasing this Saey insert stove you have chosen for a reputable stove. We wish you many happy hours of cosy heating! To get the best ecological performance and highest output from this appliance please follow these installation and operating instructions. -
Page 5: Fuel: Wood
3. FUEL: WOOD This stove burns wood only. The best results are obtained with dry wood. Logs sawn to size, cleaved and stored in a well-ventilated place (at least 1 year, preferably 2), give the best results because: they produce considerably more heat than damp or green wood they produce much less smoke than damp or green wood they deposit less soot on the sides of the stove, the flue and window than damp or green wood... -
Page 6: Combustion Air
Under no circumstances should you allow air to come in from rooms or cellars containing volatile or inflammable substances. Saey insert stoves can only be used when the door of the insert stove is closed. For the air consumption of your particular insert stove see the table in point 2. -
Page 7: Initial Use And Diagram
All local regulations, including national and European standards, must be followed when installing the appliance. Only an appliance connected by an accredited installer guarantees compliance with the architectural and fire prevention regulations. These rules must be followed to ensure the correct and safe operation of the stove. - Page 8 DIAGRAM Sordo 60 – 70 – 80 and 80 flatline Fig. 1 A. : Cold air inlet (convection) B. : Hot air outlet (convection) C. : Combustion air regulator D. : Catch OPENING AND CLOSING THE DOOR Place the handled supplied in the opening of the catch (D). Pull the catch towards you to open the door and push it away from you to close it.
-
Page 9: Combustion Principle
8. COMBUSTION PRINCIPLE This stove was developed for semi-slow burning. Loaded fully with wood and operating on a slow burn the stove will burn through the night with sufficient embers left over the next day to relight the fire. It is also possible to set the stove to a very slow burn (no flames). We do not recommend this for the following reasons: a) it causes insufficient burning which pollutes the air extremely heavily and unnecessarily b) this inadequate burning gives rise to extra smoke which deposits tar on the sides of the... - Page 10 SETTINGS Combustion air regulator (C) This controls the amount of air needed for combustion and therefore the heat produced. It is located on the top right-hand side of the door (see figs 1 and 2). Open: slide to the right Close: slide to the left The greater the supply, the more air is allowed into the stove, the more heat the stove produces, and the more wood is consumed.
-
Page 11: Cleaning
RELOADING Open the air inlet fully (C) Open the door carefully. Use the poker to spread the glowing logs over the bottom. Place new logs on the embers. Close the door and allow the fire to resume. Select a setting. PLEASE NOTE! It is recommendable to load no higher than the vermiculite walls, or to load no more wood than the normal quantity given in table 2. -
Page 12: Maintenance
It is recommended to clean the stove when it is cold. WINDOW In most cases the window "Air wash" system and the vermiculite covering on the walls help keep the window clean for longer. However, if the window becomes dirty, you should: open the door use a spray or cleaning gel on the inside of the window. - Page 13 CLEANING THE FLUE The flue must be swept every year. To do this the smoke damper must be removed from the appliance. To remove the smoke damper follow the instructions below with care. How to remove the smoke damper 1) After opening the door you can remove baffle plate D. To do this, place your hand on catch C and push the back of the catch upwards.
- Page 15 BROKEN WINDOW The pyroceramic window is solidly made and will not crack through heat. However, it can be broken through a lack of care. Read and apply the tips below to avoid damage. 1. Never allow logs to protrude from the front or the front log will break the window. 2.
-
Page 16: Troubleshooting
11. TROUBLESHOOTING Abnormal operation is usually the result of incorrect usage. If you are of the opinion that something is not working as it should, check the following. If you are unable to resolve the problem, then contact your installer. Symptom Possible cause Remedy... -
Page 17: Guarantee
12. GUARANTEE Your Saey appliance has a 2-year guarantee on all manufacturing faults from the date of purchase, provided it is used in compliance with the operating instructions. Your receipt or bill, stating the date of purchase is your proof of guarantee.
