Sigma Metalytics Precious Metal Verifier PRO 2601 Quick Manual page 11

Press [ ]
█
Measure
Gold-Gold Pure
Top arrow
in red region:
Veri er reading
is not consistent
with selected metal
Gold-Gold Pure
Plated surface or excessive relief-
ip sample over if possible
INTERPRETATION
Silver-Silver Pure
Ready - Place Sample
Other possible readings below:
1.80
1.81
Silver-Silver Pure
2.91
2.20
Top red arrow = sample too small
Use smaller sensor if possible
Silver-Silver Pure
Silver-Silver Pure
1.59
1.57
A red arrow means treat reading with caution:
GOOD READING
Verifier & Thru
1.59
readings consistent
with selected metal
1.57
1.59
Readings will di er
signi cantly
2.8
Bottom arrow
in red region:
Thru reading is
not consistent with
DIM
selected metal
Silver-Silver Pure
1.59
Bottom red arrow= sample too thin
Use smaller sensor if possible
1.57
