READ AND SAVE THESE INSTRUCTIONS

ULTRA-SORB

MODEL

S team Dis p er si on P anel

Installation, Operation,

and Maintenance Manual

For pressurized steam applications

Table of Contents

Need help?

Do you have a question about the ULTRA-SORB XV and is the answer not in the manual?

Questions and answers

Summary of Contents for DriSteem ULTRA-SORB XV

Page 1 READ AND SAVE THESE INSTRUCTIONS ULTRA-SORB ® MODEL S team Dis p er si on P anel Installation, Operation, and Maintenance Manual For pressurized steam applications...
Page 2: Table Of Contents
OPERATION ............. . Ultra-sorb XV operation ........19 Sequence of operation .
Page 3 2.0" 36.3 • 1" (DN25) connection, same as * Consult DriSteem if face height is less than 17" (432 mm) for 1.5" dimension A; tubes or less than 24" (610 mm) for 2.0" tubes. • 2" (DN50) connection, dimension A L Overall width + 1"...
Page 4: Installation
INSTALLATION Field assembly UNPACK THE DISPERSION ASSEMBLY • Remove shipping materials from the dispersion assembly, being careful not to bump or scrape the white PVDF dispersion tube insulation. • Do not lay dispersion tubes (if shipped loose by request or by shipping necessity) across or under anything that could compress or damage the insulation.
Page 5 INSTALLATION Field assembly LAY OUT THE PANEL COMPONENTS Note: These assembly instructions are for Ultra-sorb Model XV panels shipped Orient the panel components on a large, ﬂ at working surface. unassembled by request or as required. Panels with overall height more ATTACH THE FLANGES than 98"...
Page 6: Piping
INSTALLATION Piping FIGURE 4-1: ULTRA-SORB MODEL XV PIPING COMPONENTS WITH ON/OFF SHUTOFF VALVE, FLOAT SWITCH, PRESSURIZED STEAM SOURCE Applications with control cabinet operating internal heat exchanger. From Ultra-sorb Model XV pressurized steam dispersion panel steam source Install inlet strainer within 3' (1 m) of Ultra-sorb Modulating steam Model XV.
Page 7 Connection end of Insulated steam header supply tubing (see inset below) Header Cold ﬁ ll water Ultra-sorb XV dispersion panel Steam trap On/off valve (optional) STS humidiﬁ er Dispersion tube Modulating Pressurized steam to heat exchanger steam valve Pressurized condensate to return main...
Page 8: Selecting The Location
INSTALLATION Selecting the location FIGURE 6-1: PLACING A DISPERSION ASSEMBLY IN AN AIR HANDLING UNIT Filters Cooling coil 10' to 15' (3 to 4.5 m) Heating coil Economizer Duct high limit humidity control control device for dispersion locations A, B Airﬂ...
Page 9 INSTALLATION Selecting the location DETERMINE STEAM DISPERSION PANEL PLACEMENT Dispersed steam must be absorbed into the airﬂ ow before it comes in contact with duct elbows, fans, vanes, ﬁ lters, or any object that can cause condensation and dripping. • Install the Ultra-sorb panel in a location where discharged water vapor will be absorbed by the airstream.
Page 10: Mounting And Support
INSTALLATION Mounting and support INSTALLATION IN A COLD AIR STREAM FIGURE 8-1: INSTALLATION IN A COLD AIR STREAM When a steam dispersion panel is installed in a duct that will carry cold air, determine the dew point temperature. If the psychrometric chart reveals that Extended trails of fog may develop saturation may occur, protection should be provided.
Page 11: Mounting In A Duct
INSTALLATION Mounting and support Where allowed, screws and drill bits must not penetrate more than 3/4" (20 Duct smoke detector mm) into the header assembly. See Figure 10-1 for allowable drill and Do not install a duct smoke detector downstream from the Ultra-sorb panel. If screw locations.
Page 12: Installation Drawings
INSTALLATION Installation drawings: Mounting in a duct FIGURE 10-1: ULTRA-SORB MODEL XV IN A DUCT (HORIZONTAL AIRFLOW ONLY) Attach duct ﬂ ange to top frame assembly No screws Humidiﬁ cation steam 1/2" Connection end inlet: (13 mm) Screws OK • 1" or 2" NPT of header (DN25 or DN50), determined by...
Page 13: Mounting In An Air Handler
INSTALLATION Installation drawings: Mounting in an air handler FIGURE 11-1: ULTRA-SORB MODEL XV IN AN AIR HANDLER (HORIZONTAL AIRFLOW ONLY) AHU width Coil width Humidiﬁ cation steam Connection end inlet: • 1" or 2" NPT of header (DN25 or DN50), determined by maximum steam capacity...
Page 14: Recommendations And Steam Inlets
Steam pressure for steam entering the heat exchanger must be least 5 psig installer. (35 kPa) to vaporize condensate in the header. OM-7655 FIGURE 12-2: LIFTING CONDENSATE WITH ULTRA-SORB MODEL XV Elevated condensate return main Ultra-sorb XV steam dispersion panel Modulating control valve 2-position shutoff control valve...
Page 15: Controls
CAUTION is coordinated by the electronic controller provided in the DriSteem control cabinet. A demand signal or space RH is sent to the DriSteem controller, and Damage from debris the controller opens/closes the two steam valves based on the signal and When drilling penetrations in the inputs including the steam dispersion panel ﬂ...
Page 16 Air ﬂ ow indication is required. Indication can be provided by a BAS input or air ﬂ ow switch wired to the DriSteem control cabinet. Wire the air ﬂ ow switch to the DriSteem control cabinet as shown in the diagram included with the unit.
Page 17 CONTROL OPTION #2 – ELECTRIC TEMPERATURE SWITCH ONLY; CONTINUOUS HEAT EXCHANGER OPERATION The DriSteem control cabinet is not provided. An electric modulating control valve is controlled by a 2-10 VDC/4-20 mA signal from a control system (BAS) or modulating humidistat. Optional air ﬂ ow switch, high limit humidistat are wired in series with 24 VAC control circuit of the modulating control valve.
Page 18 Chosen for inlet Optional if chosen humidiﬁ er Optional if chosen No - Control provided (#5) to STS - Electic or with Ultra-sorb XV Vapor-logic ® with Ultra-sorb XV by STS humidiﬁ er Control by STS humidiﬁ er Pneumatic controller...
Page 19: Optional Header Overflow P-Trap Water Seal
FIGURE 17-1: ULTRA-SORB MODEL XV CONTROL CABINET If the Ultra-sorb XV panel is used in conjunction with a DriSteem Steam-to- Steam (STS) humidiﬁ er, atmospheric steam generated from the STS is piped to the Ultra-sorb XV and distributed through the dispersion header to the 12"...
Page 20 INSTALLATION Controls FIGURE 18-1: CONTROL CABINET Status LED Controller board Wiring terminal block OM-7882 120/208/240/480V to 24 VAC transformer, 75 VAC ULTRA-SORB MODEL XV INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
Page 21: Operation
OPERATION Ultra-sorb XV operation 1. STEAM SUPPLY INLET FIGURE 19-1: ULTRA-SORB MODEL XV Humidiﬁ cation steam from the modulating steam valve (Figure 4-2) or WITH STS; STEAM INLETS DETAILED STS humidiﬁ er (Figure 19-1) passes through the steam supply inlet into the Humidiﬁ...
Page 22 OPERATION Ultra-sorb XV operation TEMPERATURE SWITCH FIGURE 20-1: ELECTRIC TEMPERATURE SWITCH The temperature switch circuit’s sequence of operation is a safety sequence: In the unlikely event that excessive header condensate cools the heat exchanger while humidifying, the temperature sensor drops below operating temperature,...
Page 23: Sequence Of Operation
Important: If the steam valve and heat exchanger control is to be provided directly by a separate BAS controller (Control Option #4 without use of DriSteem control cabinet), inputs and valve output controls must be linked to a BAS controller and sequenced as described below.
Page 24 OPERATION Sequence of operation 3. Humidification demand is provided by a control signal to the DriSteem control cabinet. When the demand signal is sufficient, steam will flow to 1) the internal heat exchanger and 2) the modulating control valve that provides steam output based on demand.
Page 25 11. A float switch is located in the steam dispersion panel header, and wired to the DriSteem controller. The switch circuit will open if condensate (water) depth in the header rises 1/2” above the heat exchanger tube.
Page 26 TEMPERATURE SWITCH With control options #2 and #3, a 2-position (On-Off) shutoff control valve is not used (see Figure 4-2). The Ultra-sorb XV internal heat exchanger operates any time pressurized steam is available to the dispersion panel. Install the temperature switch downstream of the internal heat exchanger to prevent operation of the modulating control valve if steam is not ﬂ...
Page 27 OPERATION Sequence of operation CONTROL CABINET STATUS LED The control board within the control cabinet includes a large Status LED that indicates multiple control conditions (see Figure 18-1). The Status LED is always “blinking”. It will be easy to see that the board is powered and operating because, at a minimum, it is running the Status LED.
Page 28 OPERATION Sequence of operation CONTROL BOARD ALARM OUTPUTS There are 2 dry contact outputs on the control board that can provide alarm indications to a BAS or other control system. • Terminals C-1 to NO-1 are normally open and close upon alarm condition(s) •...
Page 29: Start-Up Checklist
OPERATION Start-up checklist 1. Ensure all component wiring and piping connections are complete as CAUTION shown in the wiring diagrams provided with the unit. 2. Create demand for humidification by providing a demand signal to control Remove clear poly ﬁ lm; do not remove white PVDF insulation.
Page 30: Performance Data
• Ultra-sorb panels with 9" (225 mm) or 12" (300 mm) tube spacings have no measurable air pressure loss. • Use DriSteem’s DriCalc sizing and selection software to calculate your speciﬁ c air pressure loss. ULTRA-SORB MODEL XV INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
Page 31: Strainer, Traps, And Valves
MAINTENANCE Strainer, traps, and valves STRAINER Inspect at least twice during the ﬁ rst year. If fouled, inspect more frequently. STEAM TRAPS Verify that the steam traps are functioning properly at least twice a year. A blocked steam trap will be at room temperature. A “blowing” steam trap is hot and noisy, and the discharge pipe from it is hot for up to 30 feet (9 m).
Page 32: Dispersion Tubes And Heat Exchanger
MAINTENANCE Dispersion tubes and heat exchanger DISPERSION TUBES • If steam or condensate is evident at the sealing surface, replace the seal. • Inspect insulating material for dirt and smudges; gently clean with damp cloth and soapy water or diluted nontoxic, biodegradable cleaner/ degreaser.
Page 33: Humidifier De-Scaling Solution
Humidiﬁ er De-scaling Solution is Humidiﬁ er De-scaling Solution, available from your DriSteem representative. It corrosive. is the only cleaner/de-scaler approved for use with DriSteem humidiﬁ ers. Use Read and follow all warnings and of other cleaners/de-scalers may void your DriSteem warranty.
Page 34: Replacement Parts
MAINTENANCE Replacement parts FIGURE 32-1: ULTRA-SORB MODEL XV REPLACEMENT PARTS OM-7484b mc_101410_0835 Table 32-1: Table 32-1: Ultra-sorb Model XV replacement parts Ultra-sorb Model XV replacement parts No. Description Part No. No. Description Part No. 7 Flange, side consult factory 1 Screws, frame (package of 4) 191170-010 8 Frame assembly, top consult factory...
Page 35: Troubleshooting
• Ensure humidiﬁ cation is 43 lbs/hr (19.5 kg/h) per tube or less.. tube Note: For panels with a face height less than 17" (430 mm), contact DriSteem for assistance. • Steam main overloaded with water due to boiler • Locate cause of priming and correct.
Page 36 MAINTENANCE Troubleshooting Table 26-1: Ultra-sorb Model XV troubleshooting guide (continued) Problem Possible cause Action Control system • Incorrect control voltage • Verify control board voltage input is 24 VAC. malfunctioning • Incorrect control signal • Verify control signal is valid or RH transmitter is wired. •...
Page 37 • Control air pressure is too low • Adjust pressure. rise to humidistat set point • Temperature control switch not allowing • Consult DriSteem to assess whether installed panel is correct for (pneumatic controls) modulating steam valve to operate application.
Page 38 ULTRA-SORB MODEL XV INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
Page 39 ULTRA-SORB MODEL XV INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
Page 40: Warranty
DriSteem, or if the products have been For the most recent product information modiﬁ ed or altered without the written consent of DriSteem, or if such products have been subject to accident, misuse, mishandling, tampering, negligence or improper maintenance. Any warranty visit our Web site: www.dristeem.com...
