- Page 1 READ AND SAVE THESE INSTRUCTIONS WATER TREATMENT 200 ser ies r eve rse -o smo sis s ys t em s Installation, Operation, and Maintenance Manual...
-
Page 2: Warnings And Cautions
Dripping water can cause property damage; bacteria and mold growth can cause illness. If the IOM is missing, go to www.dristeem.com to download a replacement. Shut down the energy source Before performing service or maintenance procedures on any part of the system, verify that all energy sources are off. - Page 3 3. Close fi eld-installed manual water supply shut-off valve. mc_050808_1540 Fill in the following information for your records Date of purchase ___________________________________________________________________________________________________________ Customer's name ___________________________________________________________________________________________________________ Model number ___________________________________________________________________________________________________________ Serial number ___________________________________________________________________________________________________________ DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
-
Page 4: Table Of Contents
Diagnostics and Alarms ....... . . 17 Modbus, BACnet, LonTalk interoperability ....18 DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... - Page 5 Refer to it for information about using the keypad/display and Web interface, and for troubleshooting information. Download DriSteem literature Most DriSteem product manuals are available our website: www.dristeem.com DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
-
Page 6: Overview
24" or greater (610 mm) above: 6" (152 mm) left, right and rear and 24" (610 mm) front – less than 24" (610 mm) above: 6" (152 mm) left and right and 24" (610 mm) front and rear DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... - Page 7 Reduce concentrate fl ow by the amount of recirc fl ow used to maintain the recommended maximum system level. Recirc fl ow usage will reduce water but may decrease membrane life. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
-
Page 8: Controller
FIGURE 4-1: VAPOR-LOGIC KEYPAD/DISPLAY AND WEB INTERFACE KEYPAD/DISPLAY Mode Softkeys for direct menu access Tank status System alarms Navigation buttons for item selection System messages DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 9: Ro Supply Water Requirements
Water hardness can increase the reverse osmosis system maintenance requirements. To maximize service life and minimize maintenance for RO systems and downstream equipment, softened water is required with all DriSteem RO systems. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 10: Flow Schematic
OVERVIEW Flow schematic FIGURE 6-1: FLOW SCHEMATIC RO200-PIPING DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... - Page 11 OVERVIEW Flow schematic FIGURE 7-1: FLOW SCHEMATIC RO200-PIPING-1 DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
-
Page 12: Component Identification
Prevents backfl ow into RO module. 15 Pipe drain Drain assembly. Run to a fl oor drain. 16 Vapor-logic control board The Vapor-logic control board is mounted inside the control cabinet. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 13: Installation
INSTALLATION Piping and instrumentation arrangement FIGURE 9-1: FLOW SCHEMATIC WITH A CARTRIDGE DECHLORINATOR OM-7905 DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 14: Operation
30 seconds, press the power button OFF, and close the concentrate valve. This will hold the preservative in the pressure vessel. 3. When the system is restarted after an extended shutdown, follow initial system start-up procedures. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 15: Start-Up Checklist
fi x the system to the fl oor and/or adjacent building structure. Failure to install according to instructions can result in serious injury or death. See page 10 for instructions. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 16: Start-Up
Pump and system performance will be adversely affected if the feed/suction 7. Allow the unit to run for at least 30 minutes to flush the preservative line is restricted. solution from the system. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 17: Operating Do's And Don't's
See page 20 for instructions. 3. Close the throttle valve completely. 4. Operate the system with insufficient feed flow. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 18: Vapor-Logic Keypad/Display
Message label fl ashes when there is a Press Up or Down system message arrow to move through menus and screens Press Enter to select or confi rm DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 19: Changing Mode
Diagnostics menu. Set system demand percent and set test run time duration. During testing, the unit mode changes to Standby and the tank status changes to Test. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 20: Status Screen
Note: Your system might not have all of the items listed in this table. Menu Default Minimum Maximum Units Notes item value value value High TDS causes Alarm Message Alarm TDS setpoint DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 21: Diagnostics And Alarms
A pressure fault can be manually cleared at any time. System will try to operate every 10 consecutive seconds per hour up to 72 hours while in low pressure alarm condition. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 22: Modbus, Bacnet, Lontalk Interoperability
Modbus Holding Registers (HR1-HR2) 16 bit read/write Modbus Discrete Input Registers (DI1-DI8) single bit read only Modbus Coil Registers (DV1-DV8) single bit read/write 2. nvi LonTalk SNVTs are write-only; nvo are read-only DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... - Page 23 Modbus Holding Registers (HR1-HR10) 16 bit read/write Modbus Discrete Input Registers (DI1-DI9) single bit read only Modbus Coil Registers (DV1-DV15) single bit read/write 2. nvi LonTalk SNVTs are write-only; nvo are read-only DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
-
Page 24: Maintenance
Excessive chlorine in feed stream may require additional pre-fi ltration. The feed stream should be tested for chlorine at least once a week. Always follow proper maintenance procedures. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 25: When To Clean Or Replace Membranes
Note: Membranes on RO system are removed and inserted from the top. 4. Remove end plugs by pulling carefully. See Figure 21-2. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 26: Membrane Cleaning In The Ro System
7. Remove the empty cleaning cartridge and replace it with the original filter. 8. Restart the system. Direct the permeate to drain for five minutes. 9. Go back to normal operations. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 27: Organic Cleaning Cartridge
9. Go back to normal operations. Handle all chemicals with care. Wear protective clothing and eye protection. CAUTION The system must be fl ushed thoroughly between acid and alkaline cleaning. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 28: Storage
9. Remove the empty preservative cartridge and replace it with a new cartridge filter. 10. Restart the system. Direct permeate to drain for 15-30 minutes. 11. Go back to normal operation. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 29: System Monitoring And Record Keeping
A pressure fault can be manually cleared at any time. System will try to operate every 10 consecutive seconds per hour up to 72 hours while in low pressure alarm condition. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 30: System Operating Log
Cartridge out psi Water temperature TDS in TDS out System psi Concentrate psi Cartridge fi lter change Membrane change Recorded by Notes _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 31: Water Quality Test Strips
Total chlorine ppm Free chlorine ppm Total hardness Total alkalinity Week 1 _________ Week 3 _________ Week 5 _________ Week 7 _________ Week 9 _________ Week 11 _________ DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 32: Replacement Parts
RO system (Models 201, 202, and 203) FIGURE 28-1: RO 200 SYSTEM REPLACEMENT PARTS OM-7871 Exploded view of the each unique replacement part for the RO 200 system. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... - Page 33 TANK WATER PRESSURIZED 4.4 GAL 550029-004 DRAIN ASSY RO-200 165103-011 VALVE 1/2" SOLENOID TWO-WAY N.C. 3.35 CV 505107-050 * Specify RO system model and serial numbers when ordering. DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
-
Page 34: Subpanel
15 Mount wallplate wallphone SST 408490-021 24VAC 75V Terminal DIN rail end cap 408252-005 16 Plug 3 circuit vertical euro molex 406246-003 17 Plug 4 circuit vertical euro molex 406246-004 DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 35: Notes
Notes DRISTEEM RO 200 SYSTEM WATER TREATMENT SYSTEMS INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 36: Warranty
DriSteem, or if the products have been www.dristeem.com modifi ed or altered without the written consent of DriSteem, or if such products have been subject sales@dristeem.com to accident, misuse, mishandling, tampering, negligence or improper maintenance. Any warranty claim must be submitted to DriSteem in writing within the stated warranty period.
