- Page 1 User Guide...
-
Page 2: Smart Switch
Smart Switch Thanks for using Aztech Kyla product If you need support or help, please visit www.kyla.aztech.com... -
Page 3: Product Description
Smart Switch is a Zigbee wireless control switch, working together with other Zigbee devices by connecting to Zigbee Hub via Zigbee network. Easily turn on/off your lights with one touch using the Aztech Kyla App on your smartphone or tablet – anytime or anywhere. Packing List •... -
Page 4: Important Safety Information
Important Safety Information 1. Neutral connection is required. CEILING 2. Not for humid places such as bathroom and green house. 3. Must be used within the range of power allowable (See page 10-11) 4. If you are unsure about the way of installation, please consult a qualified electrician. -
Page 5: What You'll Need
1. A working Zigbee Hub 2. A slotted screwdriver and a Philips head screwdriver 3. A circuit tester 4. iOS or Android smart device and a Wi-Fi network connection with a router 5. Download Aztech Kyla App from Google Play/App Store Aztech Kyla App... -
Page 6: Installation Instruction
Installation Instruction 1. Turn off power at the circuit breaker that controls the switch before installation. It is recommended to use a circuit tester to make sure the circuit is off. 2. Open the switch panel with slotted screwdriver. Live Load Neutral 3. - Page 7 4. Double–check to confirm wirings are correct and no wire is bare. 5. Place the switch into wall and mount the screws from the existing switch. 6. Press the switch panel onto the snap plate.
-
Page 8: Con Guration
1. Turn on power, the flashing LED lights show that the switch is in a state of pairing. 2. Open the Aztech Kyla App and add your smart device step by step through the App. 3. Scene settings (only for scene switches), go to the Smart Scenes in app, set scenes for the added devices. - Page 9 Devices in Use Blue Light = Red Light = Switch is Off Switch is On Blue Light = Red Light Flashes Once = Switch is Off Scene Opens...
-
Page 10: Technical Speci Cations
Technical Speci cations Product Dimensions: 86 x 90 x 38mm Voltage: 250V~, 50/60Hz Alarm Sensitivity: 6% LEL ± 3% LEL Wireless Protocol: Zigbee HA Operating Temperature: -20~60°C Working Humidity: ≤ 80% Operating Frequency: 2.4GHz, IEEE 802.15.4 Encryption Mode: AES-128bit Dynamic Encryption Transmission Distance: 60m (Open Area) - Page 11 Smart Switch (1 gang) Model: T20W1Z Input: 2.4A, 250V~, 50/60Hz Max.Load L1: 600W Smart Switch (2 gang) Model: T20W2Z Input: 4.8A, 250V~, 50/60Hz Max.Load L1: 600W Max.Load L2: 600W Smart Switch (3 gang) Model: T20W3Z Input: 2.4A, 250V~, 50/60Hz Max.Load L1: 200W Max.Load L2: 200W Max.Load L3: 200W...
- Page 12 Smart Dimming Switch Model: T20D1Z Input: 0.6A, 250V~, 50/60Hz Max.Load L1: 150W Smart Scene Switch Model: T20S3Z Input: 0.2A, 250V~, 50/60Hz Smart Curtain Switch Model: T20C1Z Input: 0.2A, 250V~, 50/60Hz...
-
Page 13: After Sales Service
After-sales Service 1. Warranty period shall be valid for 1 year since the date of purchase (it’s subject to purchase invoice; if lost, the device’s date of production shall prevail). For any malfunction caused by inferior quality (normal usage), the company will repair it for you free of charge. - Page 14 ©2018 Aztech Technologies Pte Ltd. All rights reserved.
