Page 1: User Manual
USER MANUAL ITV102EW PlayXtreme2 Wireless INTERNET TV HUB... - Page 2 Easy Start Guide © © © © COPYRIGHT 2012 ALL RIGHTS RESERVED COPYRIGHT 2012 ALL RIGHTS RESERVED COPYRIGHT 2012 ALL RIGHTS RESERVED COPYRIGHT 2012 ALL RIGHTS RESERVED v.1. v.1. v.1. v.1.2 2 2 2 No part of this document may be reproduced, republished, or retransmitted in any form or by any means whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying, recording, information recording, or through retrieval systems without the express written permission.
-
Page 3: Table Of Contents
About the Product ......................4 Package Contents ................... 5 Device Design ....................6 Getting Started ....................... 8 Connecting the Aztech PlayXtreme2 Wireless Internet TV Hub ....9 Main Menu ........................10 File Browser ....................10 Music ......................11 Movie ......................11 Web ........................ -
Page 4: About The Product
Aztech PlayXtreme2 Wireless Internet TV Hub redefines home entertainment with a whole new level of interactive, intuitive and innovative TV experience. Powered by the latest Android 2.3 platform, Aztech PlayXtreme2 Wireless Internet TV Hub converts a regular TV to an Internet-enabled one, transforming TV viewing experience to an engaging adventure with the integrated capabilities of the Internet, computer, TV and media player. -
Page 5: Package Contents
Package Contents Package contents are listed below. For any missing items, please contact your dealer immediately. Product contents vary for different models • ITV102EW (Aztech PlayXtreme2 Wireless Internet TV Hub) • Wireless Qwerty Remote Control • HDMI Cable • 5V 2.0A DC Power Adapter •... -
Page 6: Device Design
Easy Start Guide Device Design LABEL STATUS DESCRIPTION Network No network connection On - Amber Connected to the network Status LED A – Amber Initializing LED A - Off Complete initialization LED B- Blue Initializing, device is switch On LED B- Off No Power is being supplied on the device Page 6 of 32... - Page 7 Easy Start Guide LABEL DESCRIPTION Power Press and hold the Power button to switch OFF/ON the device. DC IN 5V 2.0A DC Input port HDMI Connecting HDMI cable Connecting a USB device Connecting to a modem/router Connecting a USB device Connecting a USB device Micro SD Connecting a Micro SD Card...
-
Page 8: Getting Started
Easy Start Guide Getting Started Before moving ahead to setup your network, it is a good idea to draw out a network diagram to help identify your network devices and plan out how to connect these devices. The illustration below is an example of a network diagram. Page 8 of 32... -
Page 9: Connecting The Aztech Playxtreme2 Wireless Internet Tv Hub
5. Aztech PlayXtreme2 Wireless Internet TV Hub will switch ON and Android logo will be displayed. 6. The Aztech PlayXtreme2 Wireless Internet TV Hub will initialize in less than 60 seconds and will go to the main menu. Page 9 of 32... -
Page 10: Main Menu
File Browser This section allows you to browse the files saved on your external HDD, USB thumb drive and MicroSD card connected to your Aztech PlayXtreme2 Wireless Internet TV Hub. 1. Connect your external HDD, USB thumb drive and MicroSD card to your Aztech PlayXtreme2 Wireless Internet TV Hub. -
Page 11: Music
Music This section allows you to browse and play the music saved on your external HDD, USB thumb drive and MicroSD card connected to your Aztech PlayXtreme2 Wireless Internet TV Hub. 1. Connect your external HDD, USB thumb drive and MicroSD card to your Aztech PlayXtreme2 Wireless Internet TV Hub. -
Page 12: Web
Easy Start Guide This section allows you to browse the Internet. Ensure that your Aztech PlayXtreme2 Wireless Internet TV Hub is connected to your Router/Modem and Internet connection is UP. Page 12 of 32... -
Page 13: Picture
Picture This section allows you to browse the pictures saved on your external HDD, USB thumb drive and MicroSD card connected to your Aztech PlayXtreme2 Wireless Internet TV Hub. 1. Connect your external HDD, USB thumb drive and MicroSD card to your Aztech PlayXtreme2 Wireless Internet TV Hub. -
Page 14: Settings
Easy Start Guide Settings This section allows you to configure your Aztech PlayXtreme2 Wireless Internet TV Hub. Settings will have the following features: • Wireless & Networks • Ethernet • Display • Applications • Account & sync • Privacy • Storage •... - Page 15 ITV101E for this feature to work. 1. On the Main Menu select Settings then select Wireless & networks 2. Click Wireless to enable Aztech PlayXtreme2 Wireless Internet TV Hub’s Wireless connection. 3. Click Wi-Fi Settings to search for the available wireless network 4.
- Page 16 Ethernet connection. 3. Click Ethernet Settings if you want to configure your Ethernet IP addresses. Display This allows you to configure and set Aztech PlayXtreme2 Wireless Internet TV Hub output mode. 1. On the Main Menu select Settings then select Display 2.
-
Page 17: Compatibility Mode
2. Click Unknown sources to Enable Unknown sources. By default this feature is disabled. Click Unknown sources again to disable the feature. Compatibility Mode This allows you run old application on your Aztech PlayXtreme2 Wireless Internet TV Hub by enabling this feature. 1. On the Main Menu select Settings then select Application. - Page 18 3. Select an Application that you would like to configure. Limit applications This allows you to limit the number of applications running on your Aztech PlayXtreme2 Wireless Internet TV Hub. 1. On the Main Menu select Settings then select Application.
- Page 19 2. Click Factory default if you want to restore the device to its factory default. Update system This allows you to change the current firmware installed on your Aztech PlayXtreme2 Wireless Internet TV Hub. 1. On the Main Menu select Settings then select Privacy.
- Page 20 3. Select Keyboard settings if you want change the default keyboard set on the device. Date & Time This allows you to change and set the default date and time format on your Aztech PlayXtreme2 Wireless Internet TV Hub. 1. On the Main Menu select Settings then click Language & keyboard.
-
Page 21: Applications
This allows you to view the current firmware version of your Aztech PlayXtreme2 Wireless Internet TV Hub. Applications This section allows you to select and run the pre-installed application on your Aztech PlayXtreme2 Wireless Internet TV Hub. Page 21 of 32... - Page 22 Easy Start Guide This section allows you to watch movies from PPTV movie list. Page 22 of 32...
-
Page 23: Wireless Qwerty Remote Control
Easy Start Guide Wireless Qwerty Remote Control Note: The Wireless Qwerty Transceiver is beside the battery pack. Connect the Wireless Qwerty transceiver on your ITV102EW for the Wireless Qwerty Remote Control to work. LABEL DESCRIPTION Press to increase the volume. - Page 24 Easy Start Guide Press to launch the selected application. Press to switch OFF the ITGV102EW. Press to launch the Main Menu Press to go back to the previous window Press the arrow keys to scroll through the applications. Press OK to select of launch application. Touchpad use your finger to translate the motion and position to a relative position on screen.
- Page 25 Easy Start Guide Connecting the Wireless Qwerty Remote Control on your ITV102EW 1. Unpack your ITV102EW and connect the device as shown in the diagram. Switch ON your ITV102EW PlayXtreme2 Internet TV Hub and wait for the device to initialize.
- Page 26 Easy Start Guide 4. Connect the Wireless Qwerty Remote Control Transceiver to any of the available USB port of your ITV102EW. 5. Switch On the Wireless Qwerty Remote Control, the Amber LED will switch ON then followed by Blue LED will switch ON when it is connected with the Transceiver.
- Page 27 Easy Start Guide Using your Wireless Qwerty Remote Control 1. Connect the Wireless Qwerty receiver on your Aztech PlayXtreme2 USB port. 2. Ensure that your Wireless Qwerty remote control has a battery and switched 3. Use the touchpad to move the arrow position to a relative position on the screen.
-
Page 28: Frequently Asked Questions
How do I install new application on my device? How do I install new application on my device? Save the apk file on your Micro SD card or Thumbdrive then connect it to your Aztech PlayXtreme2 Wireless Internet TV Hub’s Micro SD card slot or USB port. - Page 29 Easy Start Guide 6. Click Open to run the new application installed on your Aztech PlayXtreme2 Wireless Internet TV Hub. How do I un How do I un- - - - install an application? How do I un How do I un...
-
Page 30: Safety Precautions
Easy Start Guide Safety Precautions Do not open, service, or change any component. Only qualified technical specialists are allowed to service the equipment. Observe safety precautions to avoid electric shock Check voltage before connecting to the power supply. Connecting to the wrong voltage will damage the equipment. - Page 31 Easy Start Guide Notes: __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ __________________________________ Page 31 of 32...
- Page 32 Easy Start Guide Aztech Technical Support Service Center Address: Hotline number: 6594 2297 31 Ubi road 1 Aztech building Email: support@aztech.com Lobby A Ground floor. Support Website: www.aztech.com/support Operating Hours Monday to Friday: 9:00am to 6:15pm Saturday: 9:00am to 1:00pm...
