Summary of Contents for Aztech Kyla
- Page 1 User Guide...
- Page 2 Smart Motion Sensor Thanks for using Aztech Kyla product If you need support or help, please visit www.kyla.aztech.com...
-
Page 3: Packing List
"grid". If a moving object blocks too many grid zones and the infrared energy levels change rapidly, the sensor is triggered. Pair with the Smart Zigbee Aztech Kyla App for an easy home security defense system Detection Window Reset Button... -
Page 4: Led States
LED States LED Slowly Blinks Once per Second: Device is searching for network LED Blinks Once: Detection and alarm LED Blinks Once per 3 Seconds: Low battery, replace batteries as soon as possible Note: The battery standby time is about 8-12 months Detection Range 6m 10m 110°... - Page 5 Operation Guide Step 1: Download Aztech Kyla App from Google Play/App Store Aztech Kyla App Step 2: Login to Aztech Kyla App, then add “Smart Motion Sensor” www.aztech.com to device list to enable the device.
- Page 6 Step 3: Open the sensor base cover and insert the battery. The device will start up immediately. Step 4: Secure the detector bracket on the wall. Recommended installation height: 2m above ground.
- Page 7 Step 5: Use the notch at the back of the sensor to clamp the bracket and secure it. Adjust the sensor bracket’s direction to maximize the detection range. Wall...
-
Page 8: Installation Tips
Installation Tips 1. Choose the correct installation direction The infrared sensor has the highest detection sensitivity when perpendicular to the walking direction. To achieve the best results, please choose the most appropriate position and direction according to the actual situation and reference range diagram for installation. -
Page 9: Technical Speci Cations
Technical Speci cations Product Dimensions: 88 x 90 x 27mm Colour: White Material of Housing: PC and ABS Wireless Standard: 2.4GHz, IEEE 802.15.4 Operating Temperature: -10~50°C Working Humidity: 10% - 90% RH Communication Protocol: Zigbee HA Communication Speed: 250Kbps Power Supply: AA Battery x 2 Detection Range: ±... - Page 10 ® ©2018 Aztech Technologies Pte Ltd. All rights reserved.
