This document sketches out the main menus (please refer to operating manual MU 7033 EN for further information).

Come back to the previous stage

Light the display during 10 seconds

MEtErin

ViSuALi

SuPErVi

NB1: If it's used with Adblue, the FLEXICOMPT AUTONOME+ must be rinsed with water after use

NB2: Since the CTD+ key is not ATEX, it must be used outside potentially explosive area

NB3: Do not plug the USB cable during data transfer.

OPERATING GUIDE

FLEXICOMPT AUTONOME+

USING THE BUTTONS

- Choose the menu option

- Display the delivery information

Unloading control

Visualization (Last measurement, Totalisers, Memorizing)

Supervisor Menu (Calibration, Season, Parameters, Maintenance,

OPTION transfer of parameters)

- Validate the displayed option

- Validate a fault

Reset the volume and record the last

measurement data

FORM DOC 124 A

GU 7033 EN I

www.alma.alma.fr

Need help?

Do you have a question about the FLEXICOMPT AUTONOME+ and is the answer not in the manual?

Page 1 FORM DOC 124 A OPERATING GUIDE GU 7033 EN I FLEXICOMPT AUTONOME+ www.alma.alma.fr This document sketches out the main menus (please refer to operating manual MU 7033 EN for further information). USING THE BUTTONS - Choose the menu option - Validate the displayed option...
Page 2 FORM DOC 124 A UNLOAD A PRODUCT 1. CONNECT THE FLEXICOMPT AUTONOME+ RESET THE METER WHAT DO YOU WANT TO DO? 1 - Continue with another compartment with the same product Install the FLEXICOMPT AUTONOME+ on the compartment If data recording is automatic, appearance of flowrate causes valve (respect the slope and rotation angles –...
Page 3 FORM DOC 124 A DISPLAY/TRANSFER* THE DELIVERY DATA VISUALIZATION OF THE LAST DELIVERY RESULTS - sub-menu MEtErin VISUALIZATION OF ALL THE DELIVERY RESULTS - sub-menu MEMoriS In case of a dispute, In case of a dispute, 8669 8669 GASoiL GASoiL those indications provide proof those indications provide proof MEtErin...
Page 4 FORM DOC 124 A LIST OF ALARMS DISPLAY MEANING ACTION oVErFLo Volume greater than 4 194 304 liters Reset the device LoW_FLo Flow rate less than the setting minimal flow rate Check the hydraulic configuration and the flowing SEnSor1 High gas detector fault (GDh) Use the maintenance menu to check the status of the detector SEnSor2 Low gas detector fault (GDl)
