Alma CRYO-TRONIQUE CO2 Operating Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
This document sketches out the main menus (please refer to operating manual MU 7092 EN for further information)
USING THE BUTTONS OF THE MICROCOMPT+
- Come back to the previous step
- Increment the blinking Digit
- Choose the menu options
- Select the next digit
- Display the delivery information
- Validate the menu option
- Validate the data
- Validate the default

Advertisement

loading
Need help?

Need help?

Do you have a question about the CRYO-TRONIQUE CO2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alma CRYO-TRONIQUE CO2

Summary of Contents for Alma CRYO-TRONIQUE CO2

  • Page 1 This document sketches out the main menus (please refer to operating manual MU 7092 EN for further information) USING THE BUTTONS OF THE MICROCOMPT+ - Come back to the previous step - Choose the menu options - Validate the menu option - Increment the blinking Digit - Select the next digit - Validate the data...

  • Page 2: Meaning Of Symbols

    CHARGING 1. CARRY OUT THE OPERATION 2. CONTINUE THE OPERATION Connect the hoses CONTINUE OPERATION PRESSURE CHARGING Start the operation Open V19 and V8 to put the pipe under pressure. Then close V19 and V8. Open V3 and V5 3. END THE OPERATION OPEN PV1 ? END OPERATION OPEN PV3 ?
  • Page 3 ANALYSIS DEGASSING 1. CARRY OUT THE OPERATION 1. CARRY OUT THE OPERATION Connect the analysis device(s) Connect the hose(s) PRESSURE ANALYSIS PRESSION RETOUR GAZ Open V19 and V18 to put the pipe under pressure. Then close V19 Open V5 to put the pipe under pressure OPEN PV1 ? ANALYSIS (PT3) OPEN PV3 ?
  • Page 4 DISCHARGING Display the delivery information 1. PREPARE THE OPERATION During an operation, the information that follow are available. Values Supply the variator are displayed 10 seconds Connect the hose(s) PUMP SUCCION SINGLE HOSE Validate with PUMP OUTLET DOUBLE HOSE PRESSURE LIQUID PRESSURIZE PUMP GAS RETURN (RG3) Open V1...
  • Page 5 RESUME Display the delivery information 1. PREPARE THE OPERATION During an operation, the information that follow are available. Values Supply the variator are displayed 10 seconds Connect the hose(s) PUMP SUCCION SINGLE HOSE Validate with PUMP OUTLET DOUBLE HOSE PRESSURE LIQUID PRESSURIZE PUMP GAS RETURN (RG3) Open V2...

  • Page 6: List Of Alarms

    LIST OF ALARMS DISPLAY MEANING ACTION STOP OPERATION Intentional interruption of the operation Continue or end the operation POWER SUPPLY PROBLEM Power outage during the operation Check the cause LOW FLOW FAULT Low flowrate (lower than minimal flowrate) Check the hydraulic system HIGH FLOW FAULT High flowrate (greater than maximal flowrate) Reduce flowrate...
