Wiring Options
1
Screw Terminal Block (Included)
2
Spring Clamp Terminal Block
Sales 800-633-0405
Module Configuration
P2-RTB
(Quantity 1)
P2-RTB-1
(Quantity 1)
Using the Hardware Configuration tool in the Productivity Suite
programming software, drag and drop the P2-08THM module
into the base configuratio
n.
Select Automatic Module Verification or No Verification and
Enable Hot Swap. Specify Temperature Scale and Burnout
Detection, and use the drop down menu to select module range
and resolution. If desired, assign a User Tagname to each input
point (channel) selected and to each Status Bit Item.
www.productivity2000.com
5
