SLX digiTop 27804R User Manual

Features Include:

• The aerial element less than 0.5mm thick
on
frame or a window
Fast and easy set-up
•
Suitable for Digital/HO and 4K Ultra HO reception in strong signal areas
•
Receives all locally available digital TV signals
•
Amplified to enhance signal strength
•
Built-in filter prevents interference from 4G mobile phone transmitters
•
Reversible choose black or white side
• -
Can be painted to match your decor
•
Multiple mounting fittings included
•

Installation Instructions

1. Plug the mini USB plug on the USB lead supplied into the USB power inserter, plug the other end
into a USB socket on the back of your TV (available on most recent TVs) or a computer as shown in
Fig. 1. If you are in a very strong signal area you may not need to use the USB power connection.
Please Note: If there is no USB socket available on your TV you can use a standard USB charger with an
output socket of 1 A or more.
2. lf your TV has a built-in digital tuner, connect the F plug from your aerial to the power inserter and
then connect the integrated coax cable from the power inserter into the RF input on your TV.
Alternatively you can use your aerial to provide TV signals to Freeview
other set top boxes. Connect the F plug on your aerial lead to the power inserter then connect the
integrated coax cable from the power inserter into the RF input on your set top box and connect
the set top box to your TV using an HDMI, SCART or RF lead as appropriate (follow your set top box
instructions).
TV
Power Inserter
ideal for mounting behind a picture
-
Fig. 1
Mini USB
Plug
™ boxes, PVRs, VCRs and
