Seating Matters MONACO Operation Manual & Product Specification page 7

MONACO ASSIST
TECHNICAL SPECIFICATION
D
I J
G
H
E
F
ii
K
L
iv
TM
B
A
C
M
MONACO™ & MONACO ASSIST™ Instruction Manual
Basic dimensions
A Overall height
B Back height
C Seat to floor height
D Inside back width
E Chair length
F Reclined length
Available seat and overall widths
G (Seat width)
380mm/15in
450mm/18in
500mm/20in
550mm/22in
600mm/24in
* Dimension excludes legrest belt. Add 35mm/1.5in if
belt is used.
Arm height options*
I Low
J High
Recline and tilt angles
ii Back angle recline
100° - 120°
25° range
iii Leg rest angle
75° - 107°
32° range
iv Angle adjustable seat
-10 ° - +20°
30° range
Seat depth options
K Min
L
Max
iii
Leg rest length
M
420mm/16.5in
Chair weight unloaded is 57 Kg/125.6 lb/10.56 Stone.
Chair user weight limit is 159 Kg/364 lb/25 Stone.
*Please note when adapting cushion thickness arm height
will be affected. Contact
for further information.
1205mm/47.5in
860mm/34in
380-500mm/15-20in
505mm/20in
870mm/34in
1090mm/43in
H (Overall width)
635mm/25in*
690mm/27in*
690mm/27in*
740mm/29in*
790mm/31in*
180mm/7in
210mm/8in
350-480mm/14-19in
490-550mm/19-22in
technical@seatingmatters.com
5
