MILANO
™
Operation Manual &
Product Specification

Advertisement

loading
Need help?

Need help?

Do you have a question about the Milano and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seating Matters Milano

Summary of Contents for Seating Matters Milano

  • Page 1 MILANO ™ Operation Manual & Product Specification...

  • Page 3: Table Of Contents

    This Operation Manual is frequently updated to ensure safe use of your product. Visit www.seatingmatters.com where you can find a free copy of the most up to date version. CONTENTS Safety instructions. Technical Specification. User Guide and Operating Instructions. Working Environment. Intellectual Property. Maintenance and Servicing. MILANO™ Instruction Manual...

  • Page 4: Safety Instructions

    2. The User must ensure that the product is in good condition before use (check all nuts and bolts are fastened, fabric in good condition etc). If there are any problems, these must be reported to your Seating Matters provider and corrected before the chair is put into use.
  • Page 5 7. The product must be used on a level, plain, hard surface with the brakes engaged to avoid it moving during use and to ensure stability. When the MILANO™ is not in transit, all the braking castors on the product must be engaged to prevent risk of injury when being used.

  • Page 6: Technical Specification

    MILANO Basic dimensions. TECHNICAL SPECIFICATION Overall height 1300mm/51in Back height 770mm/30in Seat height 540mm/21in Overall length 930mm/36.5in Footplate height adjustments. High 400mm/16in from seat 580mm/23in from seat Seat depth. (L) Seat Position 1 400mm/16in Seat Position 2 450mm/18in Seat Position 3 500mm/20in Available seat and overall width.

  • Page 7: User Guide And Operating Instructions

    (fig.1a) • Braking castors: The MILANO™ chair must be used on a plane, hard surface with the brakes engaged to ensure stability and to avoid the device moving undesirably during use. Braking castors, where provided, must be in the braked position while in use (fig.1).
  • Page 8 Tilt in Space Back Angle Adjustment Seat Belt Loops (fig.2) • Back angle adjustment: To recline the back of the chair, the user must inform the Patient then stand behind the chair, and with two hands, firmly hold the push handle while closing the release lever (fig.2a).
  • Page 9 To adjust the seat width, loosen the two grips knobs on the underside of the arm pads (fig.3a). Move the arm pads inwards to reduce seat width and outwards to increase it. Tighten the grip knobs once the desired width has been achieved. MILANO™ Instruction Manual...
  • Page 10 Manual Lever to elevate leg rest (fig.4) • Leg elevation: Before changing the angle of the elevating leg rest, the User or Patient must ensure there are no objects in the immediate environment that could obstruct the leg rest elevation or come into contact with the Patients legs.
  • Page 11 • Seat cushion: The seat cushion on the MILANO™ is a waterproof, pressure redistributing breathable foam cushion providing pressure management and comfort. The seat cushion has a label saying BOTTOM and BACK. Ensure that this label is placed at the back of the seat base and facing down., with the zip closure at the...

  • Page 12: Working Environment

    WORKING ENVIRONMENT • Dartex Multi Stretch Fabric: (Central patient contact surface). Waterproof, stain resistant, flame retardant, multidirectional stretch for pressure redistribution i.e. seat cushion, calf panels, lateral supports and seat back. • Vinyl: (Coloured material on non-patient contact surfaces). Non-absorbent, anti- bacterial, flame retardant, strong, durable material for outer arms, outside back etc.

  • Page 13: Intellectual Property

    1988 safety regulations. Regional Variations The device referred to as a "MILANO™" is a Seating Matters product category and the information included in this document reflects common features of this group of products. In some regions of the world, we supply product design variations of similar function and ease-of-use but with alternative specifications or reinforcements.

  • Page 14: Maintenance And Servicing

    Parts can only be changed by service persons trained in Seating Matters products and use only Seating Matters parts. We recommend that your chair is serviced every year by a Seating Matters approved provider for any running repairs and maintenance.
  • Page 15 Check that all nuts and bolts are present. Check that all nuts and bolts are secure. Note: If nuts or bolts need attention, contact your Seating Matters approved provider IMMEDIATELY DO NOT USE the chair until it has been serviced.
  • Page 16 www.seatingmatters.com...
  • Page 17 WE ARE HERE TO HELP For any questions or queries regarding your Seating Matters chair please email: contact@seatingmatters.com MILANO™ Instruction Manual...
  • Page 18 VIEW OUR FULL RANGE OF CHAIRS & ACCESSORIES ONLINE WWW.SEATINGMATTERS.COM www.seatingmatters.com...
  • Page 19 MILANO™ Instruction Manual...
  • Page 20 Australia Canada N.Ireland & ROI 2/6 St James Place 269 Maplegrove Rd 131 Carnamuff Road Seven Hills, Colborne Limavady NSW 2147 ON, Canada Northern Ireland Australia K0K 1S0 BT49 9JG Tel: +61 1300 001 050 Tel: +1 (905) 507 9007 Tel: +44 (0) 28 777 666 24 australia@seatingmatters.com...
