- Page 1 MONACO & ™ MONACO ASSIST ™ Operation Manual & Product Specification...
-
Page 3: Table Of Contents
CONTENTS Safety Instructions Technical Specification User Guide and Operating Instructions Working Environment Seating Matters Recycling Policy Intellectual Property Maintenance and Servicing MONACO™ & MONACO ASSIST™ Instruction Manual... -
Page 4: Safety Instructions
• Care must be taken when making the adjustments on the chair to avoid injury to the User and Patient. Only a competent person should make adjustments to the chair. If in doubt as to any of the adjustments, feel free to contact Seating Matters direct at technical@seatingmatters.com. - Page 5 • For the safety of the User and Patient and to ensure longevity of the electronics on the powered options, please ensure that your MONACO ASSIST™ is charged daily using a Seating Matters charger through the handset of the chair. For further details or replacement chargers please contact your Seating Matters provider.
-
Page 6: Technical Specification
MONACO Basic dimensions TECHNICAL SPECIFICATION Overall height 1205mm/47.5in Back height 800mm/31.5in Seat to floor height 350-500mm/14-20in Inside back width 505mm/20in Chair length 870mm/34in Reclined length 1090mm/43in Available seat and overall widths G (Seat width) H (Overall width) 380mm/15in 635mm/25in* 450mm/18in... - Page 7 420mm/16.5in Chair weight unloaded is 57 Kg/125.6 lb/10.56 Stone. Chair user weight limit is 159 Kg/364 lb/25 Stone. *Please note when adapting cushion thickness arm height will be affected. Contact technical@seatingmatters.com for further information. MONACO™ & MONACO ASSIST™ Instruction Manual...
-
Page 8: User Guide And Operating Instructions
Please call your Seating Matters provider if you have any questions on these points. This product should not be lifted at any time unless by competent persons trained in such manual handling. - Page 9 Back recline Release lever for seat adjustment angle adjustment Push handle Wing knobs for lateral support adjustment Braking castors Step for seat angle adjustment (fig.3) MONACO™ & MONACO ASSIST™ Instruction Manual...
- Page 10 • Chair Movement: To move the MONACO™and MONACO ASSIST™ around, ensure the brakes are disengaged and push using the push handle on the back. Only a competent person should move this chair. Engage the directional lock castor on the front left of the chair to control the direction of movement and for ease of manoeuvrability.
- Page 11 • Seat cushion: The seat cushion on the MONACO™ and MONACO ASSIST™ is a waterproof, pressure redistributing, breathable, medium foam cushion providing pressure management and comfort. The seat cushion will have non-slip material on one face and a zip closure on one side.
- Page 12 The patient should be encouraged to use their armrests during this elevation for stability and balance. • Hand control (MONACO ASSIST™): The seat angle adjustment and back angle recline are controlled by the electric handset, simply push the button to operate the corresponding function.
- Page 13 Do not operate the chair during charging. Charging Socket Charger connected to mains (fig.7) Light Colour Indication No Light No Power Orange Plugged in, charging Green Plugged in, fully charged Orange Light Green Light MONACO™ & MONACO ASSIST™ Instruction Manual...
-
Page 14: Working Environment
WORKING ENVIRONMENT Dartex Multi-stretch: Waterproof, stain resistant, flame retardant, multidirectional • stretch fabric for pressure management situations – i.e. seat cushion, calf panels, lateral supports and seat back. • Vinyl: Non-absorbent, anti-bacterial, flame retardant, strong, durable material for outer arms, outside back etc. Cleaning and Maintenance of Fabrics •... -
Page 15: Seating Matters Recycling Policy
• Contact your local authority or governmental agency for the regulations that apply in your area. • If you wish to have Seating Matters recycle your product and your behalf, you are welcome to return the product to our company. -
Page 16: Intellectual Property
Regional Variations The device referred to as a "Monaco™" / "Monaco Assist™" is a Seating Matters product category and the information included in this document reflects common features of this group of products. In some regions of the world, we supply product design variations of equivalent function and ease-of-use but with alternative specifications or reinforcements. - Page 17 • Frame: Check the visible parts of the frame for cracks, splits, large dents or other damage. If you find any of these things do not use. Contact your Seating Matters approved provider immediately. WE ARE HERE TO HELP For any questions or queries regarding your Seating Matters chair please contact: contact@seatingmatters.com...
- Page 18 VIEW OUR FULL RANGE OF CHAIRS & ACCESSORIES ONLINE. WWW.SEATINGMATTERS.COM...
- Page 20 Australia Canada N.Ireland & ROI 2/6 St James Place 269 Maplegrove Rd 131 Carnamuff Road Seven Hills, Colborne Limavady NSW 2147 ON, Canada Northern Ireland Australia K0K 1S0 BT49 9JG Tel: +61 1300 001 050 Tel: +1 (905) 507 9007 Tel: +44 (0) 28 777 666 24 australia@seatingmatters.com...
