  • Page 1 Bleeding the Hydraulic System Instructions...
  • Page 2 QUALITY FOR LIFE QUALITY FOR LIFE Bleeding Bleeding Bleeding instructions using AL-KO iQ7 Pressure Bleed Gun Bleeding instructions using AL-KO iQ7 Pressure Bleed Gun 1. F ill reservoir with clean brake fluid to just below the top of the sight glass. 1. F ill reservoir with clean brake fluid to just below the top of the sight glass. 2. P lace the pressure bleed gun socket gently over the neck of the reservoir applying gentle 2. P lace the pressure bleed gun socket gently over the neck of the reservoir applying gentle pressure to locate the bleed socket in place (as shown in diagram 1).
  • Page 3 AL-KO AKS3004 AL-KO AKS3004 WARNING - The end of the bleeding device hose not connected to the AL-KO iQ7 should always be submerged in a bottle of clean brake STABILISER COUPLING STABILISER COUPLING fluid. Failure to follow this procedure may result in air being pumped into the brake system and the full bleed procedure needing to be repeated.
  • Page 4 QUALITY FOR LIFE 8. C ontinue squeezing the pressure bleed gun until the brake fluid in the flexible hose attached to the bleed screw is free of air bubbles and tighten the bleed screw. Bleeding 9. R epeat the process with the next furthermost calliper away from the actuator. 10. B leed the other side of the trailer starting with the closest calliper to the actuator first as Bleeding instructions using AL-KO iQ7 Pressure Bleed Gun above. 11. Connect the trailer to the tow vehicle and turn on ignition to activate actuator. Allow the 1. F ill reservoir with clean brake fluid to just below the top of the sight glass. compressor to fully charge the actuator (approx 90 seconds). Once the compressor has 2. P lace the pressure bleed gun socket gently over the neck of the reservoir applying gentle stopped apply the brakes, and hold on for a 5 second period and release. Repeat this 4 times. pressure to locate the bleed socket in place (as shown in diagram 1). 12. C heck the brake fluid level in the reservoir. It should not exceed the top of the sight glass 3. S crew the lid in place to secure the socket.
