Teaching Positions for LPT

Table 10 – Teaching Positions for LPT
Position Taught *
P1: Gun Opened
P2: Weld Position
P3: Double Nut
P4: No Nut
*
The P1, P2, P3, P4 pin positions can be taught in any order on the standard Teach screen (i.e.,
press to select the desired parameter), and in circular order in the Step Thru Teach screen.

Teaching Positions for Generic Device

Four (4) positions (P1, P2, P3, P4) are available to teach any generic device. These positions
should be defined by the customer, based on the device specifics and the parameters that need
monitoring. To teach any of these positions, press the corresponding
P1, P2, P3, P4 pin positions can be taught in any order on the standard Teach screen (i.e., press
to select the desired parameter), and in circular order in the Step Thru Teach screen.
Please review the beginning of the Teaching the MicroView section on page 42 for more details.
TM
VeriFast
Required Position of LVDT Pin and/or
status of equipment
Weld gun fully opened
Correct part in place
and
Correctly orientated fastener
and
Weld gun closed
TWO fasteners present
and
Weld Gun closed
No fastener present
and
Weld gun closed
MicroView 1.0 – User Manual – Version 1.9
How to teach
Press the (corresponding)
button.
Press the (corresponding)
button.
Press the (corresponding)
button.
Press the (corresponding)
button.
button. Note that the
