Checking the HOME camera

Checking the CuddeLink HOME camera is similar to
checking a conven onal trail camera.

Press UP to put the camera into Armed‐Info mode.
DO NOT turn off the camera!

If you con nue to press UP status of the Home
camera will be displayed.

Remove the SD card and use your normal image
viewing method.
On the SD card is folder named \\DCIM\400CUDDY.
Within this folder are images from the CuddeLink remote
cameras. If you used a unique CL LOC then each remote
camera's images will be in a different folder within the
400CUDDY folder.
The images taken with the HOME camera are in the
\\DCIM\100CUDDY folder.
Above ‐ Contents of Home SD card. Images from Remote
cameras are in the LOC__### folders.
13

CL MENU Overview

The CL MENU items will differ depending upon if a
camera is configured as a HOME, REPEATER or REMOTE.

Home Menu Items

SETTING RANGE DESCRIPTION
One camera must be set to HOME. All other
OFF, HOME,
cameras must be REMOTE or REPEATER.
CL MODE REMOTE,
REPEATER
This assigns a LOCATION ID to each camera.
CL LOC 000 thru 999 Assign each camera a unique iden fica on
number.
Every camera on the network must be set to
CL CHAN 1 thru 16
the same channel.
Displays status informa on for each remote
camera that is connected. Press UP or
CL INFO Not applicable
DOWN to cycle thru the cameras.

Repeater Menu Items

SETTING RANGE DESCRIPTION
One camera must be set to HOME. All other
OFF, HOME,
cameras must be REMOTE or REPEATER.
CL MODE REMOTE,
REPEATER
This assigns a LOCATION ID to each camera.
Assign each camera a unique iden fica on
CL LOC 000 thru 999
number.
Every camera on the network must be set to
CL CHAN 1 thru 16
the same channel.
Use this to verify the camera is on the
CL LEVEL Signal strength
