Set Up The Remote Camera - Cuddeback CuddeLink Operating Manual

Set CL LOC to 001. This is a Loca on ID number used to
iden fy each camera. We recommend HOME always be
set to 001.
Press UP to set CL LOC to 001
Skip over CL INFO by pressing MORE
Set CL CHAN to any number. You can leave this at 1 but
we recommend you change this. Pick any channel, but
remember what you selected as all cameras must be set
to the same channel.
Set CL CHAN to any number
That is all you need to do. The HOME camera is now
setup properly. Deploy and ARM the Home camera
(Press MODE un l ARM is selected).
Note—the Home camera must be armed for the CuddeLink network
to func on.
9

Set up the REMOTE camera

Set the normal camera parameters as explained in the
camera's manual. Date, me, camera delays, etc.
Set CL MODE to REMOTE then press MORE.
Press UP or DOWN to
select Home
Set CL LOC to 002. IMPORTANT – all cameras should
have a unique CL LOC (loca on) number. We
recommend you set Home to 1 and set remotes as 2, 3, 4
and so on.
Press UP to set CL LOC to
Set CL CHAN to the same channel you set on the HOME
camera. IMPORTANT – all cameras must be set to the
same channel.
Set CL CHAN to same
channel as HOME
Leave CL DELAY and CL COUNT in the default se ngs of
CL DELAY 5 and CL COUNT 250.
10
002
Leave these set to
defaults
