Quick Start Guide for ZLX-12P and ZLX-15P Loudspeakers

Packing List

A. ZLX-12P unit, 12" Two-Way Powered Loudspeaker
OR
ZLX-15P unit, 15" Two-Way Powered Loudspeaker
B. ZLX Series Loudspeaker Owner's Manual
C. Power Cord

Instructions

1. Connect the AC power cord from a grounded line
receptacle to MAINS IN.
2. Switch POWER to ON.
3. All input channels should be turned to the left before
connecting any jack.
4. Connect the 3.5 mm mini jack, XLR or TRS cable from an
audio source to AUX IN (A), INPUT 1 (B) or INPUT2.
Electro-Voice ZLX Series Quick Start Guide
Step
A
B
Illustration
A
A
B
Part Number: F01U280690 Rev. 01
C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZLX-12P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Electro-Voice ZLX-12P

  • Page 1: Packing List

    Quick Start Guide for ZLX-12P and ZLX-15P Loudspeakers Packing List A. ZLX-12P unit, 12” Two-Way Powered Loudspeaker ZLX-15P unit, 15” Two-Way Powered Loudspeaker B. ZLX Series Loudspeaker Owner’s Manual C. Power Cord Instructions Step Illustration 1. Connect the AC power cord from a grounded line receptacle to MAINS IN. 2. Switch POWER to ON.
  • Page 2 Step Illustration 1. Ensure the pole is firmly in place. 2. Use two hands to lift the loudspeaker with the hi/lo grip handles. 3. Set the pole cup located on the bottom of the loudspeaker onto the pole. 4. Tighten the thumb screw to secure the loudspeaker to the pole. Part Number: F01U280690 Rev. 01 Electro-Voice ZLX Series Quick Start Guide...
