RHINO BOOM ROTARY MOWER 2160 Operator's Manual

Boom rotary mower
Table of Contents
  • Español

    • Introducción
    • Reconocimiento
    • Alertas de Seguridad
    • Palabras para el Usuario/Operador
    • Cortadora de Césped Industrial/Para Agricultura
    • Cumplimiento del Programa de Seguridad
    • Preparación para una Operación Segura
    • Arranque con Seguridad
    • Operación con Seguridad
    • Apagado con Seguridad
    • Estacionamiento Seguro
    • Realización de Mantenimiento con Seguridad
    • Palabras Fi Nales para el Usuario
    • Introduction Section

      • Features
        • Attention Owner/Operator
        • Before Operating this Machine
      • Rhino Limited Warranty
    • Assembly Section

      • General Assembly
      • Tractor Preparation
      • Mower to Tractor Attachment
      • Driveline Length Check Procedure
      • Attachment of Hydraulic Hoses
      • Hose Connections Electronic
      • Hoses to Valve Connections for Electronic Control (Optional)
      • Mounting the Remote Command Handle
      • Hose Connections (Direct)
      • Head Attachment
      • Hose Attachment
      • Hydraulic Relief Attachment (Optional)
      • Starting Unit
    • Operation Section

      • Operating Instructions
      • Operation
      • Standard Equipment and Specifications
      • Extra Equipment
      • Optional Equipment
      • Operator Requirements
      • Personal Protective Equipment (Ppe)
      • ROPS and Seat Belt
      • Tractor Safety Devices
      • Tractor Horsepower
      • Tractor Requirements and Capabilities
      • Tractor Ballast
      • Front End Weight
      • Power Take off (PTO)
      • Tire Spacing
      • Getting on and off the Tractor
      • Boarding the Tractor
      • Starting the Tractor
      • Dismounting the Tractor
      • Connecting Attaching Heads to the Boom
      • Pre-Operation Inspection and Service
      • Tractor Pre-Operation Inspection/Service
      • Boom Unit Pre-Operation Inspection and Service
      • Frame Assembly
      • Cutting Component Inspection
      • Blade Bolt Inspection
      • Driving the Tractor and Implement
      • Starting the Tractor
      • Brake and Differential Lock Setting
      • Driving the Tractor and Boom
      • Operating the Tractor and Implement
      • Operating the Control Valves
      • Foreign Debris Hazards/Overhead Obstructions
      • Operating Speed and Ground Speed
      • Operating the Attached Mower Heads
      • Operational Instruction
      • Shutting down the Attached Head
      • Tractor, Boom, and Attached Head Storage
      • Detaching and Storing
      • Hydraulic Relief Arm
      • Transporting the Tractor and Implement
      • Transporting on Public Roadways
      • Hauling the Tractor and Implement
      • Troubleshooting Guide
    • Maintenance Section

      • Hazards with Maintenance of Implement
      • Lubrication Information
        • Hydraulic Fluid
        • Proper Oil Level
      • Driveline Lubrication
      • Main Driveline & Cat 4 Safety Shield
      • Blade Servicing
      • Blade Sharpening
      • Blade Removal
      • Blade Maintenance
      • Blade Carrier Removal
      • Blade Carrier Inspection
      • Blade Carrier Installation
      • Basic Troubleshooting of Electronic Control Valve
      • Control Handle
      • Cylinder Rod Maintenance
      • Boom Cylinder Removal and Replacement Instructions
      • Cleaning Procedure for Small Areas - Manual
      • LEXAN Sheet Cleaning Recommendations
      • Cleaning Procedure for Large Areas - Automated
      • Other Important Instructions for All Lexan Sheets
      • Additional Important Considerations for Multiwall, Corrugated and Sign Sheet
      • Graffiti Removal from Lexan* Margard* Sheet
      • Proper Torque for Fasteners
      • Service of Spindle Housing
      • Removing Bearing
      • Inspection
      • Assembly
      • Motor & Coupling Installation
      • Taper Bushing & Sheave Installation
      • Start up Procedure
      • Storage
      • Operación

Advertisement

Quick Links

Published 06/11
This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
