PROCESS AUTOMATION
MANUAL
VisuNet GMP RM/PC 200 series
Hardware manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VisuNet GMP RM/PC 200 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pepperl+Fuchs VisuNet GMP RM/PC 200 series

Summary of Contents for Pepperl+Fuchs VisuNet GMP RM/PC 200 series

  • Page 1 PROCESS AUTOMATION MANUAL VisuNet GMP RM/PC 200 series Hardware manual...
  • Page 2 VisuNet GMP RM/PC 200 series With regard to the supply of products, the current issue of the following document is ap- plicable: The General Terms of Delivery for Products and Services of the Electrical Indus- try, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the...

  • Page 3: Table Of Contents

    VisuNet GMP RM/PC 200 series Safety ................... 5 Validity....................5 Symbols Used ..................5 System Operator and Personnel ............5 Pertinent Laws, Standards, Directives, and further Documentation6 Intended use..................6 Installation and commissioning ............6 Product Specifications............... 7 Overview ....................7 Technical Data VisuNet GMP RM/PC219..........
  • Page 4 VisuNet GMP RM/PC 200 series Accessories ..................16 2.9.1 Keyboards ..................16 2.9.2 Pedestals ..................19 2.9.3 Wall arm versions ................20 2.9.4 Wall bracket..................21 2.9.5 Hole pattern for mounting versions turnable/fix......... 21 2.9.6 Hole pattern for the wall bracket ............23 2.9.7...

  • Page 5: Safety

    VisuNet GMP RM/PC 200 series Safety Safety Validity The chapter “Safety” is valid as instruction manual. Specific processes and instructions in this instruction manual require special provisions to guarantee the safety of the operating personnel. Symbols Used This document contains symbols for the identification of warning messages and of informative messages.

  • Page 6: Pertinent Laws, Standards, Directives, And Further Documentation6

    VisuNet GMP RM/PC 200 series Safety Pertinent Laws, Standards, Directives, and further Documentation Observe laws, standards, and directives applicable to the intended use and the operating location. Observe Directive 1999/92/EC in relation to hazardous areas. The corresponding datasheets, manuals, declarations of conformity, EU-type examination certificates, certificates, and control drawings if applicable (see datasheet) are an integral part of this document.

  • Page 7: Product Specifications

    VisuNet GMP RM/PC 200 series Product Specifications Product Specifications Overview GMP (“Good Manufacturing Practice”) is a set of guidelines for assuring the quality of production processes in controlled industries and closely follow the guidelines issued by the European Commission or the FDA in the US. GMP applications are typically used in the pharmaceutical and food industries.

  • Page 8: Technical Data Visunet Gmp Rm/Pc219

    VisuNet GMP RM/PC 200 series Product Specifications The remote monitor automatically connects to The complete panel PC system has many the host using RDP, ICA or VNC, enabling via standard interfaces (network, USB, serial). The operating system used is Windows 7 the network.
  • Page 9 VisuNet GMP RM/PC 200 series Product Specifications VisuNet GMP RM219 VisuNet GMP PC219 Rated voltage 24 V DC or 115 V AC / 230 V AC Input voltage range 20 ... 30 V DC or 90 ... 240 V AC Power consumption max.

  • Page 10: Technical Data Visunet Gmp Rm/Pc221

    VisuNet GMP RM/PC 200 series Product Specifications Technical Data VisuNet GMP RM/PC221 VisuNet GMP RM221 VisuNet GMP PC221 General specifications Type Remote Monitor Panel PC Hardware Processor ® ® ™ Thin Client - 1.46 GHz Intel Intel Atom E3826 1.46 GHz ™...

  • Page 11: Technical Data Visunet Gmp Rm/Pc222

    VisuNet GMP RM/PC 200 series Product Specifications VisuNet GMP RM221 VisuNet GMP PC221 Material Surface stainless steel 1.4301 / AISI 304 Surface quality ≤ 0.8 µm Mounting type slim line housing several mounting types (pedestal, wall bracket, wall arm -...

  • Page 12: Dimensions Visunet Gmp Pc/Rm219

    VisuNet GMP RM/PC 200 series Product Specifications VisuNet GMP RM222 VisuNet GMP PC222 Software Operating system Windows 7 Embedded Windows 7 Ultimate FES (32- Standard (RM Shell 4) or bit or 64-bit) or Windows 10 IoT Enterprise LTSB (x 64)

  • Page 13: Dimensions Visunet Gmp Pc/Rm221 And Pc/Rm222

    VisuNet GMP RM/PC 200 series Product Specifications Dimensions VisuNet GMP PC/RM221 and PC/RM222 Figure 2.3 Dimensions VisuNet GMP PC/RM221 and PC/RM222 Image Sticking Note! Image Sticking Displaying a fixed pattern may cause burn-in-effects (image sticking due to the LCD characteristics).

  • Page 14: Rs232/Rs485

    VisuNet GMP RM/PC 200 series Product Specifications 2.8.1 RS232/RS485 9-pin D-sub plug required for serial device connection. Connection layout according to EIA-232 (RS232). RS232 RS485 Picture Signal Signal (Data) Carrier Detect RS485 D- Receive Data n.c. Transmit Data RS485 D+ Data Terminal Ready n.c.

  • Page 15: Supply Voltage 24 V

    VisuNet GMP RM/PC 200 series Product Specifications 2.8.5 Supply Voltage 24 V 4-pin socket required for supply voltage connection (Phoenix Contact DFK-MSTB 2,5/ 4-GF- 5,08). The VisuNet GMP KM has inverse-polarity protection. Matching plug: Phoenix Contact MSTBT 2,5/ 4-STF-5,08 Picture...

  • Page 16: Accessories

    VisuNet GMP RM/PC 200 series Product Specifications Picture Signal 12 V n.c. Accessories The following accessories are available. 2.9.1 Keyboards There are several keyboard models available. All keyboards have an antibacterial coating. For this reason the keyboards are perfectly suitable for environments with high hygienic standards.
  • Page 17 VisuNet GMP RM/PC 200 series Product Specifications TA3-K4 Touchpad Active Principle capacitive Resolution 40 Pts./mm Dimensions 66 x 50 mm Driver Microsoft Mouse ® , USB Interface Interface type Conformity Protection degree IP65 Ambient conditions Ambient temperature -20 ... 55 °C (-4 ... 131 °F) Storage temperature -20 ...
  • Page 18 VisuNet GMP RM/PC 200 series Product Specifications TA3-K6 Indicators/operating means Keyboard 105 short stroke keys Keyboard layout: US international, German, French, (further keyboard layouts on demand) Joystick Driver Microsoft Mouse ® , USB Interface Interface type Conformity Protection degree IP65...

  • Page 19: Pedestals

    VisuNet GMP RM/PC 200 series Product Specifications TA3-K8 Rated voltage via data line Indicators/operating means Keyboard 105 short stroke keys Keyboard layout: US international, German, French, (further keyboard layouts on demand) Trackball Diameter 50 mm Material [...] [...] Driver Microsoft Mouse ® , USB...

  • Page 20: Wall Arm Versions

    VisuNet GMP RM/PC 200 series Product Specifications Model number Description PEDESTAL1-150-1V-KP-G-T-304 Pedestal, turnable approx. 350°, inclination of monitor 10°, with pipe for keyboard PEDESTAL1-150-1V-KP-G-F-304 Pedestal, fix mounted, inclination of monitor 10°, with pipe for keyboard PEDESTAL1-150-1V-NP-G-T-304 Pedestal, turnable approx. 350°, inclination of monitor 10°...

  • Page 21: Wall Bracket

    VisuNet GMP RM/PC 200 series Product Specifications 2.9.4 Wall bracket Figure 2.10 Wall bracket for VisuNet GMP Model number Description WALL-BRACKET1-0-0V-G- Wall bracket 2.9.5 Hole pattern for mounting versions turnable/fix Mounting version turnable, fastening at front: Angle of turn for turnable mounting version The first stop plate is premounted for a max.
  • Page 22 VisuNet GMP RM/PC 200 series Product Specifications Figure 2.11 Turnable mounting version 1. Locking screw 2. premounted stop plate Mounting version fix: 42-50 63-64...

  • Page 23: Hole Pattern For The Wall Bracket

    VisuNet GMP RM/PC 200 series Product Specifications 2.9.6 Hole pattern for the wall bracket Wall Bracket: Ø 2.9.7 Power supply and network accessories Power Supply Model Number Description BN-24/5000-HS-10 Power supply for safe area, DIN rail mounting DATL-A2-4.0N/2.5F-2 Power cable 2x 4.0mm² +2.5m 2.5mm², wire end ferrule, length: 110 m 2DATL-A2-2.5-1...

  • Page 24: Barcode Reader

    VisuNet GMP RM/PC 200 series Product Specifications 2.9.8 Barcode Reader The VisuNet GMP can operate an barcode handheld at its TTY interface. The following products can be used at present: Barcode handheld Powerscan PSCAN-D-1D-N0-R3-10-N The PSCAN-D-1* consists of an barcode handheld with connecting cable. The connectiong cable is a 7 m long cable and a 8-pin M12 connector is mounted.

  • Page 25: Dimensions With Barcode Handheld

    VisuNet GMP RM/PC 200 series Product Specifications 2.9.9 Dimensions with Barcode handheld Dimensions VisuNet GMP PC/RM 219 with Barcode handheld 29,5 Dimensions VisuNet GMP PC/RM221 and PC/RM222 with Barcode handheld 29,5...

  • Page 26: Holder For Handheld Barcode Reader

    VisuNet GMP RM/PC 200 series Product Specifications 2.9.10 Holder for handheld barcode reader Dimensions 67,6 Figure 2.12 Abmessungen Halter für Barcode-Handheld...

  • Page 27: Installation And Commissioning

    Keep the ambient temperature below the specified maximal value. Note! The device is not delivered in sterile condition. 3.2.1 Grounding at housing Note! Pepperl+Fuchs recommand to use a cable with a core-cross section of 4 mm for grounding. Figure 3.1 Ground connection at housing...

  • Page 28: Grounding At Pedestal

    3. Insert the cable of the cable lug between the 2 washers (1). 4. Tighten the screw nut. Figure 3.2 Equipotential bonding at the housing washer lock washer screw nut cable lug 3.2.2 Grounding at Pedestal Note! Pepperl+Fuchs recommand to use a cable with a core-cross section of 4 mm for grounding.
  • Page 29 VisuNet GMP RM/PC 200 series Installation and Commissioning Figure 3.3 Ground connection at pedestal Grounding VisuNet GMP at pedestal and wall arm Note! Depending on the grounding cable you need the adequate cable lug (not included in delivery). 1. Insert the grounding cable into a cable lug (4).

  • Page 30: General Mounting Information

    VisuNet GMP RM/PC 200 series Installation and Commissioning General Mounting Information Note! Mounting with 2 persons The following mounting requires 2 persons. Note! For fastening the pedestal, use 4 screws (M8) which suit the soil conditions. Tools required for assembly...
  • Page 31 VisuNet GMP RM/PC 200 series Installation and Commissioning Running the keyboard cable through the pedestal If you use a pedestal with keyboard pipe (Pedestal1-150-1V-KP-G-T-304, Pedestal1-150-1V- KP-G-F-304, Pedestal1-150-1K-KP-G-T-304, Pedestal1-150-1K-KP-G-F-304), a wire pull is already installed for running the keyboard cable through the pedestal. Run the keyboard cable first.
  • Page 32 VisuNet GMP RM/PC 200 series Installation and Commissioning Wire pull for connection cables Connection cable Connecting Cables to VisuNet GMP (Pedestal) Connect all cables correctly. Figure 3.6 Example of connection...
  • Page 33 2. To plug up cable glands that are not in use, lightly tighten the cable gland 3. Plug the plugs in. 4. Firmly thighten the cable gland. Note! Pepperl+Fuchs recommand to use a cable with a core-cross section of 4 mm for grounding.

  • Page 34: Mounting To Wall Arm

    VisuNet GMP RM/PC 200 series Installation and Commissioning Mounting to wall arm Fastening the wall arm Caution! Danger of instability There are problems by keyboard entry. The device is not properly mounted to the wall. Ensucre that the soil is stable. The soil must be able to absorb high mechanical energy. For fastening the wall arm, use 4 screws (M8) which suit the soil conditions.
  • Page 35 VisuNet GMP RM/PC 200 series Installation and Commissioning Wire pull for keyboard cable Keyboard cable VisuNet GMP Running cables through wall arm For easier installation of the connection cables through the wall arm, wires are already installed through the wall arm and the cable glands (1).
  • Page 36 VisuNet GMP RM/PC 200 series Installation and Commissioning Mounting flexible Patch Cable (in Case of using turnable Wall Arm) Note! In case of using a turnable wall arm apply flexible patch cable Due to frequent monitor turning in live operation inflexible patch cable (1) is strained heavily within the wall bracket (4).
  • Page 37 VisuNet GMP RM/PC 200 series Installation and Commissioning Figure 3.10 Example of connection Mounting VisuNet GMP to Wall Arm 1. Attach the VisuNet GMP with 4 countersunk screws with hexagon socket (M5x16). Use a allen key (3 mm). 2. Tighten the screws (torque: 5-6 Nm) Figure 3.11...

  • Page 38: Mounting To Wall Bracket

    3. Plug the plugs in. 4. Firmly thighten the cable gland. Note! Pepperl+Fuchs recommand to use a cable with a core-cross section of 4 mm for grounding. Mounting to wall bracket Fixing the screws for wall bracket on the wall Note! For fastening the wall bracket, use 4 screws (M8) which suit the soil conditions.
  • Page 39 VisuNet GMP RM/PC 200 series Installation and Commissioning Connecting Cables to VisuNet GMP (Wall Bracket) Connect all cables correctly. Figure 3.12 Example of connection...
  • Page 40 2. To plug up cable glands that are not in use, lightly tighten the cable gland 3. Plug the plugs in. 4. Firmly thighten the cable gland. Note! Pepperl+Fuchs recommand to use a cable with a core-cross section of 4 mm for grounding. 1. Grounding Tightening the wall bracket and hooking the device 1.

  • Page 41: Commissioning Visunet Gmp Rm/Pc

    VisuNet GMP RM/PC 200 series Installation and Commissioning 2. Hook the device at the screes on the wall. Commissioning VisuNet GMP RM/PC Use a low restistance connection between device and control cabinet. Use cables with a minimum cross core-section of 2,5 mm for power supply.

  • Page 42: Appendix

    VisuNet GMP RM/PC 200 series Appendix Appendix Chemical resistance of keyboard foil The keyboard foil is manufactured from a biaxially aligned polyester-based material and therefore has a greater restistance to solvents. The foil is stronger and more durable than other standard foils used on keyboards and front panels, such as polycarbonate and PVC.
  • Page 43 VisuNet GMP RM/PC 200 series Appendix Aldehyde: Hydrocarbons: Aliphatic hydrocarbons generally gasoline Kerosene Toluol Xylene Benzene Chlorinated hydrocarbons: Chlorofluorocarbons Perchloroethylene III-Trichloroethylene Diethyl ether Methyl ethyl ketone Trichloroethylene Acids: Formic acid <10 % acetic acid <10 % Phosphoric acid <10 % Hydrochloric acid <10 %...

  • Page 44: Chemical Resistance Of The Display Foil Frame Used In Versions

    VisuNet GMP RM/PC 200 series Appendix Aldehyde: Grape juice Milk Coffee Detergent, rising agent, cleaning agent: Potash soap Detergent solutions (surfactants) Fabric softener Sodium carbonate Household chemicals (24 hours of exposure at 50 °C) Top Job Jet Dry Gumption Fantastic...
  • Page 45 VisuNet GMP RM/PC 200 series Appendix Glycerine Toluene Diethyl ether Isopropanol Xylene Ether Methanol White spirit Ethlacetate Triacetin N-Butyl acetate Acteone Acetic acid (<50%) Dibutyl Phthalate Isophorone Formic acid (<50%) Dioctyl Phthalate Cyclohexanone Hydrochloric acid (<36%) Fabric conditioner Methylethylketone Nitric acid (<10%)

  • Page 46: Change The Keyboard Ta3-K

    VisuNet GMP RM/PC 200 series Appendix Tetrahydrofuran Slight discoloration Intense examinations established that the following products caused slight discoloration: Mustard Tomato juice Tomato ketchup Lemon juice Coffee Note! Various other substances may cause the surface structure to alter. Testing and subsequent assessment still require clarification.

  • Page 47: Attach The Keyboard Ta3-K

    VisuNet GMP RM/PC 200 series Appendix 5. Remove the keyboard and put it out of the front housing. 4.5.2 Attach the keyboard TA3-K* Attach the keyboard 1. Remove the cover plate of the keyboard. 2. Replace the 8x distance bolts to 8x lock nuts. Tighten the lock nuts, torque 0,3 Nm.
  • Page 48 VisuNet GMP RM/PC 200 series Appendix Lock washer M3 Washer M3 Washer M4 Toothed lock washer M4 8. Put the cable into the board. 9. Close the bottom plate. 10.To assure the GMP capability join the joint at the keyboard with silicon professionally.
  • Page 49 VisuNet GMP RM/PC 200 series Appendix This page left blank intentionally.
  • Page 50 PROCESS AUTOMATION – PROTECTING YOUR PROCESS Worldwide Headquarters Pepperl+Fuchs GmbH 68307 Mannheim · Germany Tel. +49 621 776-0 E-mail: info@de.pepperl-fuchs.com For the Pepperl+Fuchs representative closest to you check www.pepperl-fuchs.com/contact www.pepperl-fuchs.com Subject to modifications DOCT-1798J Copyright PEPPERL+FUCHS • Printed in Germany 07/2018...
