Pepperl+Fuchs RM-320P Instruction Manual

Instruction Manual
1. Marking
VisuNet FLX – Panel Mount
Remote Monitor RM-320P-*
Personal Computer PC-320P-*
Equipment protection level Gc
ATEX certificate: UL 22 ATEX 2479 X
ATEX marking: 1 II 3G Ex ec [ic] IIC T4 Gc
IECEx certificate: IECEx ULD 22.0017X
IECEx marking: Ex ec [ic] IIC T4 Gc
Equipment protection level Dc
ATEX certificate: UL 22 ATEX 2480 U
ATEX marking: 1 II 3D Ex tc [ic] IIIC Dc
IECEx certificate: IECEx ULD 22.0018U
IECEx marking: Ex tc [ic] IIIC Dc
North America Certifcates:
OrdLoc: E223772 (UL)
HazLoc: E492874 (UL), Control Drawing 116-0478
Device suitable for mounting in:
Class I, Division 2, Groups A-D, T4
Class II, Division 2, Groups E, F, G
Class III
Device suitable for mounting in:
Class I, Zone 2, Group IIC, T4
Class II, Zone 22, Group IIIB
Class III, Zone 22, Group IIIA
Associated apparatus with intrinsically safe circuits for:
Class I, Division 2, Groups A-D
Class II, Division 2, Groups E, F, G
Class III
Associated apparatus with intrinsically safe circuits for:
Class I, Zone 2, Group IIC
Class II, Zone 22, Group IIIB
Class III, Zone 22, Group IIIA
VisuNet FLX – Panel Mount
Direct Monitor DM-320P-*
Equipment protection level Gc
ATEX certificate: UL 22 ATEX 2479 X
ATEX marking: 1 II 3G Ex ec IIC T4 Gc
IECEx certificate: IECEx ULD 22.0017X
IECEx marking: Ex ec IIC T4 Gc
Equipment protection level Dc
ATEX certificate: UL 22 ATEX 2480 U
ATEX marking: 1 II 3D Ex tc IIIC Dc
IECEx certificate: IECEx ULD 22.0018U
IECEx marking: Ex tc IIIC Dc
North America Certifcates:
OrdLoc: E223772 (UL)
HazLoc: E492874 (UL)
Device suitable for mounting in:
Class I, Division 2, Groups A-D, T4
Class II, Division 2, Groups E, F, G
Class III
Device suitable for mounting in:
Class I, Zone 2, Group IIC, T4
Class II, Zone 22, Group IIIB
Class III, Zone 22, Group IIIA
The *-marked letters of the type code are placeholders for versions of the
device.
Pepperl+Fuchs Group
Lilienthalstraße 200, 68307 Mannheim, Germany
Internet: www.pepperl-fuchs.com
2. Validity
Specific processes and instructions in this instruction manual require
special provisions to guarantee the safety of the operating personnel.
Due to constant revisions, documentation is subject to permanent change.
Please refer only to the most up-to-date version, which can be found under
www.pepperl-fuchs.com.
3. Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation,
maintenance, and dismounting lies with the plant operator.
The personnel must be appropriately trained and qualified in order to carry
out mounting, installation, commissioning, operation, maintenance, and
DOCT-7047D / 2022-06
dismounting of the device. The trained and qualified personnel must have
read and understood the instruction manual.
4. Reference to Further Documentation
Observe laws, standards, and directives applicable to the intended use
and the operating location. Observe Directive 1999/92/EC in relation to
hazardous areas.
The corresponding datasheets, manuals, declarations of conformity, EU-
type examination certificates, certificates, and control drawings if
applicable (see datasheet) are an integral part of this document. You can
find this information under www.pepperl-fuchs.com.
For specific device information such as the year of construction,
scan the QR code on the device. As an alternative, enter the serial number
in the serial number search at www.pepperl-fuchs.com.
Due to constant revisions, documentation is subject to permanent change.
Please refer only to the most up-to-date version, which can be found under
www.pepperl-fuchs.com.
5. Intended Use
The device is only approved for appropriate and intended use. Ignoring
these instructions will void any warranty and absolve the manufacturer
from any liability.
VisuNet FLX panels consist of a display unit with touch screen in
combination with a computing unit. Various display sizes (21.5 inch,
19 inch and 15.6 inch) and configurable computer units lead to highest
application flexibility. The VisuNet FLX panels are designed for Zone 2/22
and non-Ex applications.
Use the device only within the specified ambient temperature range.
The device must only be operated in the specified ambient temperature
range and at the specified relative humidity without condensation.
Use the device only within the specified ambient and operating conditions.
Take the intended use of the connected devices from the corresponding
documentation.
The device is an electrical apparatus for hazardous areas.
The device is not suitable for separating hazardous areas.
Ex components are not intended to be used alone. Mounting and usage of
Ex components in devices or systems must be certified separately.
Ex components have the U marking at the end of the certificate number.
Devices for which specific conditions of use apply have the X marking at
the end of the certificate number.
Only use the device stationary.
6. Improper Use
Protection of the personnel and the plant is not ensured if the device is not
used according to its intended use.
The device is not suitable to separate intrinsically safe circuits from non-
intrinsically safe circuits.
The device is not suitable for separating hazardous areas.
7. Specific Conditions of Use
Ensure that the device provides and maintains a degree of protection
of at least IP64 according to IEC/EN 60079-0.
The device must be installed and operated only in a controlled
environment that ensures a pollution degree 2 (or better) according to
IEC/EN 60664-1.
Only connect safety extra-low voltage circuits (SELV) or protective extra-
low voltage circuits (PELV) to the device.
The device must be installed and operated only in an environment of
overvoltage category II (or better) according to IEC/EN 60664-1.
Only connect supplies that provide protection against electric shock (e. g.
SELV or PELV).
Use the device only within the specified ambient and operating conditions.
Install the device in locations with a low risk of mechanical hazard
according to IEC/EN 60079-0 only.
Avoid mechanical impacts to the device (e. g. from heavy or sharp-
edged objects).
7.1. Requirements to Equipment
For Direct Monitor DM-320P-*
Secure the connections of the device against loosening
by suitable means.
For Remote Monitor RM-320P-* and Personal Computer PC-320P-*
Secure the connections of the device against loosening
by suitable means.
Do not use interfaces that are not intended for the use in the explosion-
hazardous area.
Do not use operating elements that are not intended for the use
in the explosion-hazardous area.
