- Page 1 NBB Controls + Components GmbH Flexibly designed complete solutions Radio Control Systems – Cable Control Systems – Infrared Control Systems Operating instructions USA/Canada PocketEvo Transmitter Receiver...
- Page 2 NBB Controls + Components GmbH...
- Page 3 Contents General information ..............4 Transmitter PocketEvo ............. 6 ®...
-
Page 4: General Information
Disregarding these recommendations puts you and others in danger! NBB refuses any warranty and liability in such cases. The radio control system is used to control machines and transmit data. In explosive atmospheres or for the control of machines for the transport of persons it may not be used, unless specifically authorized by the manufacturer for this application. - Page 5 Warranty NBB grants a functional warranty of 12 months from the date of sale on all NBB radio control systems (transmitter, receiver, charger). Working hours and material costs are included in the warranty. Shipping costs shall be at the expense of the buyer. Worn parts, relays, rechargeable batteries and batteries are excluded from the warranty.
- Page 6 NBB Controls + Components GmbH Transmitter PocketEvo ® Variations PocketEvo minor PocketEvo media PocketEvo magna ® ® ® PocketEvo minor-LCD PocketEvo media-LCD PocketEvo magna-LCD ® ® ® Type of Push button Proportional (optional 1-, 2- or 3-steps) Edition 06/17...
- Page 7 1. Loosen the retaining screw 2. Remove the cover If the NBB radio control system won’t be used for a long period of time, it is strongly recommended remove the battery from transmitter and charge the battery approx. every 4 weeks. This prevents deep discharge of the battery and enhances its service life.
- Page 8 NBB Controls + Components GmbH Transmitter PocketEvo ® Operation of the system > Switching the transmitter on and off CDC-key (Customer Data Collection) – The transmitter can only be started with the CDC-key inserted. – If the CDC-key is not present, the display changesbetween “no” and “tA”.
- Page 9 > Channel number During operation the set channel can be displayed by pressing the “Frequency switching” key. For transmitters without an LED display, the information is displayed in the monochrome. Please refer to the technical documents for the exact position of the “On/Horn” and “Frequency switching”...
- Page 10 NBB Controls + Components GmbH Transmitter PocketEvo ® SMP-Technologie – Surface Mounted Push buttons > Changing the Surface Mounted Push buttons – Switch off the transmitter and remove the battery. – Unscrew the threaded sleeve with the supplied special key and pull it outwards.
-
Page 11: Technical Data
< 100 mA bei 3 V RF output < 750 μW Protection class IP 65 Operating ambient temperature – 20 to + 70 °C PocketEvo minor / PocketEvo minor-LCD: approx. 600 g ® ® Weight (without battery) PocketEvo ® media / PocketEvo ®... - Page 12 Error 11 “Er” and “11” turn off Transmitter Eviroment too strong Error RFID “no” and “tA” no CDC-Key ask CDC-Key from NBB Error Config. “no” and “CF” No Configurations in CDC-Key ask Configurations from NBB Error Battery “Er” and “bt”...
- Page 13 Meaning warning identification LED Figure Reason Solution Warning 1 “01” flash Button 1 is near failure status contact NBB Service Warning 2 “02” flash Button 2 is near failure status contact NBB Service Warning 3 “03” flash Button 3 is near failure status...
- Page 14 Phone: 800 706-4489 (only USA) Phone: +1 804 262-4846 Fax: +1 804 262-0596 sales@nbbcontrols.com www.nbbcontrols.com Headquarter NBB Controls + Components GmbH Otto-Hahn-Straße 3 – 5 75248 Ölbronn-Dürrn GERMANY Fon: +49 7237 999-0 Fax: +49 7237 999-199 sales@nbb.de www.nbbcontrols.de Edition 07/17 · We reserve the right to alter specifications without notice.
