TQC MANUAL CUPPING TEST
SP4400
1 SAFETY PRECAUTIONS
•
Never put limbs in the clamping area.
•
Always have the clamp properly tightened during testing
•
Never test chattering or breaking materials like glass or acrylics that chatter when
exerted to high forces.
Avoid using it in over-high or over-low temperature environment .
•
Avoid humidity .
•
2 PRODUCT DESCRIPTION
Revolutionary apparatus for testing the resistivity of coatings at various stages of deformation in accordance
with ISO 1520. The built in gear-box minimizes the manual force which is required to deform the test panel,
allowing to perform a smooth deformation. The degree or deformation is digitally displayed at a resolution of
0.01 mm. Mandatory test in Qualicoat, QIB and GSB accredited laboratories.
2.1 Specifications
Max. sample thickness steel:
Max. sample thickness aluminum:
Max. sample width
Max sample length
Punch diameter
Die diameter
Gauge resolution
Cupping range/stroke
Displacement per revolution
Instrument height
Instrument diameter
Cylinder diameter
Base diameter
Total weight
Materials
3 STANDARDS
EN-ISO 1520, BS 3900 E4
Look up the appropriate standard for a correct execution of the test.
4 WHAT'S IN THE BOX?
TQC Manual cupping test
•
Digital micrometer
•
Calibration plate
•
1mm Allen key
•
•
User manual
: 0,8 mm
: 1,2 mm
: 95 mm
: infinite
: 20 mm /hardened steel
: 27 mm /hardened steel
: 0,01 mm
: 14 mm
: 0.50 mm per handle revolution
: 370 mm (excl. lamp/magnifier)
: 230 mm (excl. lamp holder)
: 236 mm
: 300 mm
: 16 kg.
: Anodized aluminum, Stainless steel, Powdercoated steel, Tungsten
Carbide steel
1 |
Advertisement
Table of Contents
Related Manuals for TQC SP4400
Summary of Contents for TQC SP4400
- Page 1 TQC MANUAL CUPPING TEST SP4400 1 SAFETY PRECAUTIONS • Never put limbs in the clamping area. • Always have the clamp properly tightened during testing • Never test chattering or breaking materials like glass or acrylics that chatter when exerted to high forces.
- Page 2 Place the digital micrometer on the cupping tester as shown below. Insert the micrometer in the Ensure it is straight and pressed Keep the micro meter secure and designated hole on top of the TQC against the housing. straight and fix the micrometer by Manual Cupping Test.
- Page 3 8 CALIBRATIONS • Prior to the first use and later at regular intervals the TQC Manual Cupping Test should be calibrated. • Check the indenter and panel clamps for any dirt or impurities. If dirty clean by using a soft cloth and non aggressive solvent like Iso Propyl Alcohol.
- Page 4 11 DISCLAIMER The right of technical modifications is reserved. The information given in this manual is not intended to be exhaustive and any person using the product for any purpose other than that specifically recommended in this manual without first obtaining written confirmation from us as to the suitability of the product for the intended purpose does so at his own risk.
