- Page 1 XR17V354 and XR17V358 Evaluation Board User Manual MaxLinear Confidential • www.maxlinear.com • 001UMR00 TBD/18 001UMR00...
- Page 2 XR17V354 and XR17V358 Evaluation Board User Manual Revision History Revision History Document No. Release Date Change Description 1.0.1 June 2011 Legacy Exar EVB Manual 001UMR00 November 2018 For updated board - complete re-write. November 2018 001UMR00...
-
Page 3: Table Of Contents
MPIO Pins and Test Points ............................9 Power ....................................9 Software ..................................9 Software Drivers..............................9 Windows Device Manager / Port Settings Tab....................10 XR17V354 and XR17V358 EVB Schematics ....................11 XR17V354EVB / XR17V358EVB PCB....................... 12 XR17V354 / XR17V358 EVB Bill of Materials ....................13 November 2018 001UMR00... - Page 4 Figure 5: PCIe and Expansion Interface....................... 4 Figure 6: XR17V358IB-E8-EVB Block Diagram ....................5 Figure 7: DB68 Connector ............................ 7 Figure 8: Device Manager / Port Setting tab example ..................10 Figure 9: XR17V354 / XR17V358 EVB Top Silkscreen..................12 November 2018 001UMR00...
- Page 5 XR17V354 and XR17V358 Evaluation Board User Manual List of Tables List of Tables Table 1: Evaluation Board Ordering Part Number ....................3 Table 2: XRA1405 to SP339 Connections......................6 Table 3: Factory Settings............................7 Table 4: DB68 Pin-out ............................8 Table 5: RS485/422 Headers for Each Channel ....................
-
Page 6: Introduction
Introduction Introduction The XR17V354 and XR17V358 evaluation boards provide a platform to evaluate the features and performance of the XR17V354 and XR17V358. The XR17V354 and XR17V358 are 4-channel and 8-channel PCIe UARTs, respectively. They are available in the same package and are pin compatible, therefore they utilize the same evaluation board. The evaluation board revision is 4.0. -
Page 7: Figure 2: Bottom View Of The Xr17V358Ib-E8-Evb
XR17V354 and XR17V358 Evaluation Board User Manual Reference Documentation Figure 2: Bottom View of the XR17V358IB-E8-EVB Figure 3: Top View of the XR17V358IB-0A-EVB Figure 4: Bottom View of the XR17V358IB-0A-EVB November 2018 001UMR00... -
Page 8: Ordering Information
Description XR17V354IB-0A-EVB A single 4-channel XR17V354 PCIe UART and four SP339 Transceivers are installed. Two 4-channel XR17V354 PCIe UARTs and eight SP339 Transceivers are installed in a master / slave XR17V354IB-E4-EVB configuration. A master 4-channel XR17V354 PCIe UART, a slave 8-channel XR17V358 PCIe UART and twelve SP339 XR17V354IB-E8-EVB Transceivers are installed. -
Page 9: Evaluation Board Overview
2 XR17V358 are installed. The PCI interface of the master device is connected directly to the PCIe connector. The master device communicates with the slave device via MaxLinear’s proprietary expansion interface, illustrated in Figure 5. The PCIe interface on the slave device is not used and should be unconnected. -
Page 10: Figure 6: Xr17V358Ib-E8-Evb Block Diagram
XR17V354 and XR17V358 Evaluation Board User Manual SPI Interface: Ch 1 SP339 To DB68 UART Channels Ch 2 SP339 MPIO1 EN_M PCIe P0-4 MPIO2 3.3V XR17V358 EN_M Master P4-7 Ch 3 SP339 MPIO3 EN_M XRA1405 MPIO4-15 Ch 4 SP339 Expansion... -
Page 11: Transceiver Control Connections
XR17V354 and XR17V358 Evaluation Board User Manual Transceiver Control Connections: Transceiver Control Connections: The XRA1405 outputs are sequentially (P0 to P15) connected to the MODE0, MODE1, SLEW and TERM pins of each SP339 transceiver as shown in Table 2: Table 2:... -
Page 12: System Set-Up / Powering Up
XR17V354 and XR17V358 Evaluation Board User Manual System Set-Up / Powering Up System Set-Up / Powering Up Jumpers Jumpers are factory installed per Table 3 to configure the EVB for operation. Jumpers may be added or removed per the description. Refer to the product Data Sheets for additional information. -
Page 13: Table 4: Db68 Pin-Out
XR17V354 and XR17V358 Evaluation Board User Manual Pin-out Connectors Table 4: DB68 Pin-out Pin Number Signal Name Pin Number Signal Name Pin Number Signal Name Pin Number Signal Name RXD7 RXD3 RXD8 RXD4 RIN7 RIN3 RIN8 RIN4 DCD7 DCD3 DCD8... -
Page 14: Mpio Pins And Test Points
Power Power is connected when the PCIe board is plugged into the computer’s PCIe bus. Each XR17V354 and XR17V358 has an internal buck regulator that is powered by the PCIe bus 3.3V supply and produces a 1.2V output. This 1.2V output may be used to drive the 1.2V power required by the same XR17V35x, or alternatively the 1.2V may be supplied externally. -
Page 15: Windows Device Manager / Port Settings Tab
Device Manager / Port Setting tab example After the ports are set, they can be tested using any serial testing tool or MaxLinear’s Super GUI which can be found from the XR17V358 product page, under Design Tools / Evaluation Hardware and Software, Software Drivers. -
Page 16: Xr17V354 And Xr17V358 Evb Schematics
The XR17V358IB-0A-EVB uses the same schematic, except the slave components are not populated. The XR17V358IB-E4-EVB uses the same schematic, except the slave PCIe UART is the XR17V354 (the XR17V358 is pin compatible to the XR17V354) and the transceivers for channels 5-8 are not populated. -
Page 17: Xr17V354Evb / Xr17V358Evb Pcb
XR17V354 and XR17V358 Evaluation Board User Manual XR17V354EVB / XR17V358EVB PCB XR17V354EVB / XR17V358EVB PCB Figure 9: XR17V354 / XR17V358 EVB Top Silkscreen November 2018 001UMR00... -
Page 18: Xr17V354 / Xr17V358 Evb Bill Of Materials
XR17V354 and XR17V358 Evaluation Board User Manual XR17V354 / XR17V358 EVB Bill of Materials XR17V354 / XR17V358 EVB Bill of Materials Table 8: XR17V358IB-0A-EVB Bill of Materials Manufacturer / Part Item Reference Designator Description Number C11, C12, C13, C14, C16, C17, C18, C19, C20, C21, CAP CER 0.1UF 16V X7R... - Page 19 XR17V354 and XR17V358 Evaluation Board User Manual XR17V354 / XR17V358 EVB Bill of Materials Table 8: (Continued)XR17V358IB-0A-EVB Bill of Materials Manufacturer / Part Item Reference Designator Description Number U11, U16, U24, U25, U34, U35, U36, U37 RS232/RS485/RS422 MaxLinear Transceiver with...
-
Page 20: Table 9: Xr17V358Ib-E8-Evb Bill Of Materials
XR17V354 and XR17V358 Evaluation Board User Manual XR17V354 / XR17V358 EVB Bill of Materials Table 9: XR17V358IB-E8-EVB Bill of Materials Manufacturer / Part Item Reference Designator Description Number C1, C2, C3, C4, C5, C6, C7, C8, C9, C10, C11, C12, C13, CAP CER 0.1UF 16V X7R... - Page 21 XR17V354 and XR17V358 Evaluation Board User Manual XR17V354 / XR17V358 EVB Bill of Materials Table 9: XR17V358IB-E8-EVB Bill of Materials Manufacturer / Part Item Reference Designator Description Number R102 RES SMD 191 OHM 1% Panasonic 1/10W 0402 ERJ-2RKF1910X TP1, TP4, TP16, TP20, TP27, TP31, TP32, TP33, TP34,...
-
Page 22: Table 10: Xr17V354Ib-0A-Evb Bill Of Materials
XR17V354 and XR17V358 Evaluation Board User Manual XR17V354 / XR17V358 EVB Bill of Materials Table 10: XR17V354IB-0A-EVB Bill of Materials Item Reference Designator Description Manufacturer / Part Number C11, C12, C13, C14, C16, C17, C18, C19, C20, C21, CAP CER 0.1UF 16V X7R... - Page 23 Products are not authorized for use in such applications unless MaxLinear, Inc. receives, in writing, assurances to its satisfaction that: (a) the risk of injury or damage has been minimized; (b) the user assumes all such risks; (c) potential liability of MaxLinear, Inc.
