- Page 1 RFID table scanner UR21-MR-01 UR21-MS-01 User’s Manual...
- Page 2 © DENSO WAVE INCORPORATED, 2017 All rights reserved. The copyright for this manual is held by DENSO WAVE INCORPORATED. Any copying or reproduction of this material without prior consent is strictly prohibited. QBdirect is a registered trademark of DENSO WAVE INCORPORATED.
-
Page 3: Table Of Contents
Introduction ................i Customer Registration and Inquiries ............ii Safety Precautions ..............iii Cleaning ................vi Chapter 1 System Configuration ............- 1 - 1.1 System Configuration ............- 1 - 1.2 Items Included in the Package ..........- 2 - 1.3 Software Used ............... -
Page 4: Introduction
If it is judged by DENSO WAVE INCORPORATED that malfunction of the product is due to the product having been dropped or subjected to impact, repairs will be made at a reasonable charge even within the warranty period. -
Page 5: Customer Registration And Inquiries
Customer Registration and Inquiries Customer Registration To allow us to provide our customers with comprehensive service and support, we request that all customers complete a Member Registration Form. Registered members will be offered the following privileges. Latest upgrade information ... -
Page 6: Safety Precautions
Safety Precautions Be sure to observe all these safety precautions. Please READ through these instructions carefully. They will enable you to use the scanner correctly. Always keep this manual nearby for speedy reference. Strict observance of these warnings and cautions is a MUST for preventing accidents that could result in bodily injury and substantial property damage. - Page 7 WARNING To System Designers: When introducing the scanner in those systems that could affect human lives (e.g., medicines management system), develop applications carefully through redundancy and safety design which avoids the feasibility of affecting human lives even if a data error occurs.
- Page 8 CAUTION Improper handling of the scanner may cause heat generation/fuming/device failure. Keep the following precautions in mind when using: Never disassemble or modify the scanner; doing so could result in an accident such as break or fire. Doing so could result in a fire or electrical shock. Never disassemble ...
-
Page 9: Cleaning
CAUTION Improper handling of the scanner may cause heat generation/fuming,device failure. Keep the following precautions in mind when using: When disconnecting the AC adapter from the wall socket, hold the AC adapter body not the power cable. The power cable may be broken, resulting in a burnt AC adapter, electrical shock, or fire. ... -
Page 10: Chapter 1 System Configuration
Chapter 1 System Configuration This chapter describes the hardware required for the UHF RFID data collection system and the software for the RFID table scanner. 1.1 System Configuration To use the UHF RFID data collection system using the RFID table scanner, the following hardware and software, as well as the the RFID table scanner, are required: Using the DLL supplied by us, application programs can easily be built in the computer in a general-purpose development environment (Visual Studio, etc.). -
Page 11: Items Included In The Package
(with insert nut) Antenna stay Cover locking screw Locking screw Coaxial cable (overall length 2000 mm) Items contained in the package UR21-MR-01 (interface: RS-232C/USB) • Controller URCT-M21 • Antenna URAN-R2 • Cover • Cover locking screw • Coaxial cable (overall length 2000 mm) •... -
Page 12: Chapter 2 Names And Functions Of The Parts
Chapter 2 Names and Functions of the Parts Controller Indicator LEDs Indicate the operating status of the RFID table scanner. For details, see Chapter 6. DC jack Accepts the DC plug of the AC adapter. RS-232C communication connector Connects to a computer, etc. via the interface cable. -
Page 13: Antenna
Antenna reading surface Antenna Put an RF tag over this surface to read it. Antenna rear side connector Antenna side coaxial connector Connects the antenna cable. Put the cable in the housing groove as shown in this figure. CAUTION If installing the antenna under the desk, use a dedicated stay (optionally available). RF tags are read using radio waves. -
Page 14: Chapter 3 Preparations For Use Of The Table Scanner
Antenna side coaxial connector (in the case of using UR21-MR-01) (3) If the UR21-MR-01 is used in combination with two antennas, attach the second antenna’s coaxial cable connector to the controller’s antenna connector ATN2. Push the connector firmly until it is locked. -
Page 15: Connecting The Scanner To The Computer (When Rs-232C Interface Used)
Connecting the scanner to the computer (when RS-232C interface used) (1) Connect the RS-232C interface cable to the controller’s communication connector. Secure the connectors with their screws. Note: Run the cable through the cover in advance and then connect it. (2) Connect the RS-232C interface cable to the computer, Lock the connector. - Page 16 (3) Plug the AC adapter into the controller’s power jack. When the AC adapter is plugged into the outlet, its power is turned on. Note: Run the cable through the cover in advance and then connect it. (4) Attach the cover to the controller’s connector. ...
-
Page 17: Connecting The Scanner To The Computer (When Usb Interface Used)
Connecting the scanner to the computer (when USB interface used) (1) Connect the USB cable plug to the controller’s USB connector. Note: Run the cable through the cover in advance and then connect it. (2) Connect the USB cable to the computer, Note: This figure shows an example of a computer. - Page 18 (3) Plug the AC adapter into the controller’s power jack. When the AC adapter is plugged into the outlet, its power is turned on. Note: Run the cable through the cover in advance and then connect it. (4) Attach the cover to the controller’s connector. ...
-
Page 19: Chapter 4 How To Read Rf Tags
Chapter 4 How to Read RF Tags An example of reading an RF tag using the UR21-MR-01 and UR-21-MS-01 is given below. POS processing at clothing shop (1) Put the RF tag close to the antenna to allow the scanner to read the information from the tag. - Page 20 An example of reading an RF tag using the UR21-MR-01 is given below. Entrance/exit gate control (1) Put the RF tag close to the antenna to allow the scanner to read the information from the tag. RF tag Antenna For its reading range, see Appendix 1.
-
Page 21: Chapter 5 Rfid Table Scanner Control And Parameter Settings
Chapter 5 RFID Table Scanner Control and Parameter Settings Perform RFID table scanner control and parameter settings by using commands from a control device such as a computer via the RS-232C/USB interface. 5.1 Read Control The RFID table scanner can perform the following operations to RF tags: For details, see “DLL Reference Manual, Chapter 4, Function Specifications”... -
Page 22: Chapter 6 Status Check
Chapter 6 Status Check The operating status of the scanner is indicated by the four status indicator LEDs shown below. Status indicators Status PW (green) COM (red) ANT2 (orange) ANT1 (orange) Power off Unlit Unlit Unlit Unlit Power on, start-up process Unlit Unlit Unlit... -
Page 23: Chapter 7 Upper-Level Communication
(Note 1) To use the USB-COM interface, it is necessary to install the Active USB-COM port driver, which is supplied by Denso Wave, on the computer. This driver is available for free from our QBdirect website. If you need a CD containing this driver, please contact us at the address described in “Introduction.”... -
Page 24: Chapter 8 Troubleshooting
Chapter 8 Troubleshooting If data cannot be correctly read/written from/to an RF tag: Check item Corrective action If not, move it. Is the RF tag located at the read/write If the scanner is too close to or too far away from the RF tag, it position? may fail to read/write from/to the RF tag. -
Page 25: Appendix 1 Specifications
Appendix 1 Specifications Radio Wave Specifications (860MHz band) Item Specification Communication frequency 865.7 MHz to 867.5 MHz (at 600kHz intervals) for Europe (a total of 4 channels) Communication frequency 866.1 MHz to 867.5 MHz (at 200kHz intervals) RF interface for Russia (a total of 8 channels) Applicable standards Conforms to ISO/IEC 18000-63 (GS1 EPC Gen2) -
Page 26: Communicable Rf Tag Specifications
Communicable RF tag specifications Item Specification Communication frequency 865 to 868 MHz and 915 to 928 MHz Communication system Half duplex Modulation system PR-ASK 80 to 100% Reader/writer ↓ Encoding system Pulse interval [PIE] RF tag Communication speed 40 kbps Modulation system Backscatter ASK RF tag... - Page 27 20 to 80%RH (see Note 1) External dimensions Controller: 90 * 108.5 * 31 mm Antenna for UR21-MR-01 : 200 * 200 * 17.5 mm Antenna for UR21-MS-01: 200 * 200 * 5 mm Coaxial cable: Overall length 2000 mm...
-
Page 28: Scanning Performance
Scanning Performance The communication range based on our standard RF tag (Avery Dennison AD-229R6) is illustrated below. The reference values given below were measured with the scanner and RF tag in the absence of any object/substance that may affect radio waves around the scanner. ... -
Page 29: Writing Performance
Writing performance Tag memory writing requires more electric power than tag memory reading: If the same output level is set for reading and writing, the writing range may be smaller than the reading range. Therefore, even if an RF tag is read successfully, a write error may occur due to insufficient RF tag power. - Page 30 RFID table scanner UR21-MR-01 UR21-MS-01 User’s Manual Preliminary Edition. October. 2017 DENSO WAVE INCORPORATED , AUTO-ID Business Unit Engineering Division...
- Page 31 DENSO WAVE INCORPORATED 1, Yoshiike, Kusagi, Agui-cho, Chita-gun, Aichi-pref. 470-2297 JAPAN http://www.denso-wave.com/...
