Treasure Garden UM800xSL Assembly And Operation Manual

Starlight collar tilt
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

UM800xSL
9'
O C
Starlight Collar Tilt
Assembly and Operation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UM800xSL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Treasure Garden UM800xSL

Summary of Contents for Treasure Garden UM800xSL

  • Page 1 UM800xSL 9’ Starlight Collar Tilt Assembly and Operation Guide...
  • Page 2 Thank you for purchasing Treasure Garden’s Starlight Collar Tilt Umbrella. Please remove all contents from the package, inspect and review checklist. STARLIGHT COLLAR TILT CHECKLIST - Finial B - Canopy/Mainframe C - Bottom Pole D - Power Cord/Transformer Note: Use only the Power Cord/Transformer supplied.
  • Page 3 Connect bottom pole plug to canopy/mainframe plug. Twist plug clockwise together to secure connection. Insert bottom pole into canopy/mainframe pole. Line up button with hole and snap into place.
  • Page 4 Turn umbrella in upright position. Insert bottom pole into free standing base or through table top. Insert power supply/transformer into umbrella pole. Connect other end of power supply/transformer into wall outlet. Note: The transformer output power is 12V. It is normal for transformer to get warm after long period of use.
  • Page 5 S T E P 2 Operating Umbrella Crank handle clockwise to open umbrella to its fully open position. To turn umbrella on or off, press on/off switch located on collar housing. On/Off Switch To tilt, simply twist the collar in clockwise direction.
  • Page 6 S T E P 3 Closing Umbrella Twist collar in counter-clockwise direction to bring umbrella back to its original upright position. Turn umbrella off by clicking switch to off position. Off Switch To store umbrella To close, turn crank in counter-clockwise away, unplug power supply/transformer direction to close...
  • Page 7 WARRANTY: In the event that warranted factory service Treasure Garden warrants this product is required, Treasure Garden will assume (in residential use) to be free from defects the responsibility of the return freight in original materials and workmanship for a...
  • Page 8 ©2018 Treasure Garden, Inc. - All Rights Reserved. 7/18...
