Sloan NAVAL 110 Installation Instructions Manual

Exposed Closet Flushometer —
1-1/2" Top Spud
NAVAL 110/111
NAVAL 115
NAVAL 116
®
The Sloan Naval is a piston type Flushometer of superior design. It employs an
exclusive Xpelor By-Pass Feature that ensures consistent metering operation
even under the most severe water conditions. Navel Brass, Stainless Steel and
High Grade Thermoplastics insure that vital inside parts will not be affected by
corrosive water conditions. The Naval is especially suited for marine use, gray
water systems or any other application where aggressive or corrosive water
conditions would reduce the life and efficiency of an ordinary flushometer.
The Naval Flushometer is designed for easy installation and maintenance and
Sloan Valve Company warrants its Naval Flushometer to be made of first class materials, free from defects of material or workmanship under normal use and
to perform the service for which they are intended in a thoroughly reliable and efficient manner when properly installed and serviced, for a period of three years
(1 year for special finishes) from date of purchase. During this period, Sloan Valve Company will, at its option, repair or replace any part or parts which prove to
be thus defective if returned to Sloan Valve Company, at customer's cost, and this shall be the sole remedy available under this warranty. No claims will be
allowed for labor, transportation or other incidental costs. This warranty extends only to persons or organizations who purchase Sloan Valve Company's products
directly from Sloan Valve Company for purpose of resale.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE
COMPANY RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.
Exposed Urinal Flushometer —
1-1/4" Top Spud
NAVAL 180
Exposed Urinal Flushometer —
3/4" Top Spud
NAVAL 186
comes complete with a metal oscillating Non-Hold-Open lever actuator,
Bak-Chek
salt water applications), vacuum breaker flush connection, spud coupling, and
wall and spud flanges.
The following instructions will serve as a guide when installing the Sloan Naval
Flushometer. As always, good safety practices and care are recommended when
installing your new Flushometer. If further assistance is required, contact your
nearest Sloan Representative office.

LIMITED WARRANTY

NAVAL
Installation INSTRUCTIONS
PISTON TYPE FLUSHOMETER
FOR EXPOSED CLOSET AND URINAL
INSTALLATIONS
Certified
Exposed Closet Flushometer —
1-1/2" Back Spud
NAVAL 120
NAVAL 121
NAVAL 122
®
control stop, adjustable tailpiece (ground joint tailpiece available for
NAVAL I.I.
Code No. 0816176
®
Rev. 1
Made in the U.S.A
