1.2 COMPONENTS
A. Inlet
B. Outlet
C. Motor
D. Housing
E. Impeller
F. Motor Mounting Plate
1.3 SHIPPING
The IPVB is shipped on a pallet covered by a cardboard box.
STANDARD PACKING LIST
The IPVB is shipped with a junction box and drain installation
kit. If other components are shipped, these will appear as
separate items on the shipping packing list.
NOTE:
All single phase fans ae shipped with a capacitor and junction
box connected via conduit. The capacitor is located INSIDE
the junction box. Please do not discard.
SHIPPING WEIGHT*
Model
300
350
400
500
*Weight includes the shipping pallet
1.4 WARRANTY
ENERVEX products are warranted for a period of two (2)
years following the date of invoice. Replacement or repair
will be at ENERVEX's discretion, provided factory inspection
shows a defect in material or workmanship.
Complete warranty conditions are available from ENERVEX.
B
Lbs
100
120
150
200
C
D
E
Fig 1
5
3002600 08.17
F
AIR
FLOW
A
