INSTALLATION GUIDE
FBUS-HSE/H1 LD
Fieldbus Network Module Linking Device
This document provides a quick guide to install and configure
the FBUS-HSE/H1 LD network module. For more detailed
information on using the network module, refer to the
FBUS-HSE/H1 Linking Device (LD) User Manual.
Features
•
Foundation Fieldbus H1 interface to control network
•
High Speed Ethernet interface
•
Runs on 11 to 30 VDC power
•
0 to +55 °C operation
Kit Contents and Optional Equipment
Your kit contains the following items:
•
FBUS-HSE/H1 LD network module
•
Accessories—This installation guide and your software CD
You can order the following optional equipment from National
Instruments:
•
Panel mount accessory, part number 777609-01
•
Cables
•
24 VDC power supply
Installation
Complete the following steps to install the FBUS-HSE/H1 LD.
1. Use a flat-bladed screwdriver to open the DIN rail clip to the
unlocked position, as shown in Figure 1.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for National Instruments FBUS-HSE/H1 LD
Summary of Contents for National Instruments FBUS-HSE/H1 LD
- Page 1 Panel mount accessory, part number 777609-01 • Cables • 24 VDC power supply Installation Complete the following steps to install the FBUS-HSE/H1 LD. 1. Use a flat-bladed screwdriver to open the DIN rail clip to the unlocked position, as shown in Figure 1.
- Page 2 Rail Clip Locked Rail Clip Unlocked Figure 1. DIN Rail Clip 2. Mount the FBUS-HSE/H1 LD onto a 35 mm DIN rail or onto a panel mount accessory. Installing onto a DIN rail: a. Hook the lip on the rear of the FBUS-HSE/H1 LD onto the top of a 35 mm DIN rail and press the FBUS-HSE/H1 LD down onto the DIN rail, as shown in Figure 2.
- Page 3 National Instruments: a. Snap the panel mount accessory onto the module as shown in Figure 3. Figure 3. Mounting the FBUS-HSE/H1 LD onto a Panel Mount Accessory b. Lock the rail clip. c. Mount the FBUS-HSE/H1 LD and panel mount accessory onto the desired surface.
-
Page 4: System Requirements
Figure 4. Ethernet Network Connection System Requirements A DHCP server in the network is required for the FBUS-HSE/H1 LD to obtain its IP address and start up. Fieldbus Network Connection Connect the FBUS-HSE/H1 LD to a Fieldbus H1 network using the 9-position DSub connector on the FBUS-HSE/H1 LD. - Page 5 11–30 VDC primary power – supply Figure 6. FBUS-HSE/H1 LD Power Connector Pinout Connect the primary power supply to the center V and C pair. You can connect an optional backup power supply to the left V and C pair.
- Page 6 Figure 7. Mechanical Dimensions Technical Support Resources NI Web Support National Instruments Web support is your first stop for help in solving installation, configuration, and application problems and questions. Online problem-solving and diagnostic resources include frequently asked questions, knowledge bases, product-specific troubleshooting wizards, manuals, drivers, software updates, and more.
- Page 7 Spain 34 91 640 0085, Sweden 46 0 8 587 895 00, Switzerland 41 56 200 51 51, Taiwan 886 2 2528 7227, Thailand 662 992 7519, United Kingdom 44 0 1635 523545 © National Instruments Corp. FBUS-HSE/H1 LD Installation Guide...
- Page 8 FieldPoint™, National Instruments™, NI™, and ni.com™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents .
