Philips IR dongle Quick Start Manual

Hide thumbs


Advertisement

IR Dongle
v2.0
Quick Start Guide
Work with IR Dongle
v2.0 in the field
This dongle is for use with compatible
phones to enable IR (infrared) for field
configuration and grouping of EasyAir,
office/industry sensor families.
Importance of installer's positioning for correct commissioning
of SNH200 using IR Dongle
For compatible phones, refer to the Technical Downloads.
Tips for Use:
Note: Remember to switch off the LEDs when not in use to
save battery and for longer lifetime
Working with Philips Field Apps
You must first register for Philips Field Apps to receive a
username and password, then download Philips Field Apps
from Google Play Store.
Luminaires
Ordering data
Commercial product name
IR Dongle v2.0
Technical specifications
Maximum mounting height
16m/50ft
Allow all pop-up messages in Philips Field Apps (e.g. "Allow
Philips Field Apps to record audio? Allow Philips Field Apps
to access photos, media and files on your device?").
Aim the emitter of the dongle at the target luminaire using
the IR dongle and check the light behavior according to
steps in the App to confirm the command gets executed.
(light dimmed, light blinks twice, etc.)
Invert Signal in the Preferences within app when the LED
blinks 6 times.
12NC
929001678906
Ambient temperature range
From -10 ºC to 50 ºC
December 2018
