Pt 1000 (IEC 751B, 1000 Ω / 0 °C)
Heat curves
20 | © Danfoss | 2018.05
Ω
°C Ω
1600
-50 803
1500
-40 843
-30 882
-20 922
1400
-10 961
0 1000
1300
10 1039
20 1078
30 1117
1200
40 1155
50 1194
1100
60 1232
70 1271
80 1309 1000
90 1347
100 1385
900
110 1423
120 1461
800
130 1498
140 1535
150 1573
1.8 2.2 2.6 3.0 3.4
120
110
1.4
100
90
1.0
80
70
0.6
60
50
40
0.2
30
20
10
-30 -20
-50 -25 0 25 50 75
-10 0 10
°C
100 125 150
