SCS LABCOTER 2 Operator's Manual page 57

OM-610-1002-1
Parameter Description (Configuration)
Parameter
inPt Input Type and Range
ruL Scale Range Upper Limit
rLL Scale Range Lower Limit
dPoS Decimal point position
CtyP Control Type
CtrL Primary Output Control Action
ALA 1 Alarm 1 Type
PhA 1 Process High Alarm 1 value*
PLA 1 Process Low Alarm 1 value*
bAL 1 Band Alarm 1 value*
AHY 1 Alarm 1 Hysteresis *
ALA 2 Alarm 2 Type
PhA 2 Process High Alarm 2 value*
PLA 2 Process Low Alarm 2 value*
bAL 2 Band Alarm 2 value*
AHY 2 Alarm 2 Hysteresis*
LAEn Loop Alarm Enable
Inhi Alarm Inhibit
USE 1 Output 1 Usage
USE 3 Output 3 Usage
diSP Display Strategy
Cloc Configuration Mode Lock Code
PDS-2010
Description
SECTION 6 MAINTENANCE
Operator's Manual
West Factory Default
JC
1200
-200
1
SnGL
REv (reverse acting)
P_Hi
Range Max.
Range Min.
5
1
P_Lo
Range Max.
Range Min.
5
1
diSA
nonE
Pri
A1_d
1
20
