Congratulations on purchasing a high-quality Rollei product. You have acquired a modern
Multi Scanner with excellent technical features and respective accessories, which is particularly
easy to operate. Please study this information in detail, observing safety instructions, in particular.
The scanner comes with a 2-year warranty. You will need the enclosed warranty card and your
sales receipt in the event of the Multi Scanner developing a fault. Keep these in a safe place
Please include the instruction manual when passing on the scanner to a third party.
Note:
• Only use the scanner for the intended purposes. Where the scanner has been used for
other purposes, resulting in damage, the warranty shall be invalidated. Injuries and
damage to the environment can also only be avoided if used correctly.
Main features
• Multi scanner with 5.1 megapixels image size
• High scanning quality of 1800 dpi and 2400 dpi (interpolated)
• Digitize slides, negatives and photos in a matter of seconds
• Automatic and manual exposure
• Automatic colour balance
• Power supply via USB cable
Contents of box
The box contains the following components:
1. Rollei Multi Scanner PDF-S 340
2. USB-Cable
3. Negative Film Holder
4. Positive Slide Holder
5. 4 in 1 mount for photos and business cards(13x18cm, 10x15cm, 9x13cm and 9.1x5.5cm)
6. OCR CD
7. AC/DC adapter
8. Instruction manual
Dear customer,
together with the instruction manual.
1
Advertisement
Table of Contents
Related Manuals for Rollei PDF-S 340
Summary of Contents for Rollei PDF-S 340
- Page 1 Dear customer, Congratulations on purchasing a high-quality Rollei product. You have acquired a modern Multi Scanner with excellent technical features and respective accessories, which is particularly easy to operate. Please study this information in detail, observing safety instructions, in particular.
-
Page 2: Table Of Contents
Contents Introduction Main features Contents of box Contents 4 1. Safety Instructions 6 2. Description of parts 7 3. Loading Slides 8 4. Loading Negatives 9 5. Inserting photos 10 6. General operations Quick Start Operation Guide Capture Capture: Mirror/Flip/(Hard Key) Capture mode Capture: Edit Menu 6.6.1 Live view Capture/Edit Menu... - Page 3 6.9.7 Playback: Home 6.9.8 Playback: No File 6.10 Film Type 6.11 Effect 6.12 Crop proportion 6.13 Business Card Reader 6.13.1 Name Card Recognition 6.13.2 Edit Window 6.13.3 Manually Editing 6.13.4 Add a business card 6.13.5 Software Features 6.14 Resolution 6.15 Language 6.16 USB mode 24 7.
-
Page 6: Description Of Parts
2. Description of parts 1. ON/OFF switch 2. Control LED photo scan mode 3. Control LED film scan mode 12. Right button 4. SCAN button 13. MODE button 5. TFT-LCD colour monitor 14. Slider for selecting scan template 6. Switch for scan mode 15. -
Page 7: Loading Slides
3. Loading Slides Hold up the slide toward the light. Face the trademark side of the slide away from you. Look through the slide and it should appear normally (not a mirror image). Now turn the slide so the image is upside down while looking at the same side. Open the slide holder at the marked spot on the top. -
Page 8: Loading Negatives
4. Loading Negatives Hold up the negative toward the light. As you look through the negative you should be able to read the small negative numbers normally (not a mirror image). Now turn the negative so the image is upside down while looking at the same side. Open the negative holder at the marked spot on the top. -
Page 10: General Operations
6. General operations Note: Maybe there is some difference between the preview image and saved image, please subject to the image that you saved in SD card. 6.1 Quick Start Please insert the memory card into the device, and do not take out the memory card when the device is operating, otherwise the device will be powered off automatically. -
Page 11: Operation Guide
6.2 Operation Guide Home: Main menu When the Film scanner mode is selected, the following main menu will appear: ① Language mode Capture Resolution ② USB mode ③ Capture mode ④ Playback mode ⑤ Film Type ⑥ Resolution ① ② ③ ④ ⑤ ⑥... -
Page 12: Capture
6.3 Capture Capture Resolution Capture Crop After the welcome page, the above menu will appear. You can press LEFT/RIGHT button for desired menu, and then press ENTER button to confirm the selection. Adjust brightness and color of image You can adjust brightness and color of image in capture mode. When enter into capture mode, press ENTER button, following picture will show on: EV means brightness;... -
Page 13: Capture Mode
Flip Press RIGHT button to upside down image Live view indicator 6.5 Capture mode Once entered capture mode, there will be an indicator on the left top corner to indicate it is in live view mode. You can also press ENTER button, then press LEFT/RIGHT button to adjust EV value, press ENTER button again to confirm and this will take you back to live view mode. -
Page 14: Capture: Save
6.6.2 Capture: Save Once you press SCAN button, the preview (live view) image will be selected and shown on the screen. This will take between 1~2 second with 2 icons shown on the left side of the screen. The SAVE icon will be highlighted for you to confirm by pressing the ENTER button, after the above step, the display will go back to live view mode (preview) 6.6.3 Capture: Cancel... -
Page 15: Playback
6.9 Playback P r e s s L E F T / R I G H T b u t t o n t o g o t o theplayback mode, or access the main menu by the pressing the Home icon/ MODE button at any time. -
Page 16: Playback: Rotate/Save
button. Once user select the picture stored in internal memory or memory card which intended to be modified, press ENTER button again to bring out the edit mode for modification. Exit ENTER ENTER Slide show mode Single picture mode Use LEFT/RIGHT Edit mode button to scroll picture If there is no memory card inserted or no image in internal memory, TFT will auto display 20 frames... -
Page 17: Playback: Exit
6.9.5 Playback: Exit Once user select Exit function in edit menu, the display will go back to slide show starting with the current picture without any change Exit ENTER 6.9.6 Playback: Delete Select delete icon with LEFT/RIGHT button then press ENTER button, that will delete the present selected picture and next picture will be shown. - Page 18 6.9.8 Playback: No File If there is no picture when enter playback mode, a No picture symbol will show on screen Playback No File ENTER 6.10 Film Type When the Film scanner mode is selected, you can change the film type by entering Film Type menu or access the main menu at anytime by pressing the Home icon/MODE button.
- Page 19 6.11 Effect When the Photo scanner mode is selected, you can change colour effect by the Effect menu, or you access through the main menu by pressing the Home icon/MODE button anytime. Press LEFT/RIGHT button for Effect and press the ENTER button to confirm Effect Color ①...
- Page 20 6.13 Business Card Reader 1. Insert the CD in the CD-ROM 2. A pop-up installation interface will appear after you put the CD in the CD-ROM 3. Install Business Card Reader. NIMOCARD is a professional business card scanning and management s o f t w a r e .
- Page 21 When scanning is completed, you can close the capture window or click on the main window at the back to bring up the preview window as show below. 6.13.2 Edit Window Selected one of the name card listed in the preview window and then click on the "Edit"...
- Page 22 6.13.4 Add a business card User can also create a new business card by clicking on the "New" button on the left side of the main window. 6.13.5 Software Features 1. Multi-language OS support Nimocard uses unicode encoding standard and can be installed on various operating systems in different languages.
- Page 23 6.14 Resolution Change the resolution by entering Resolution menu on the device or access the main menu by Home icon/MODE button. Press LEFT/RIGHT button for Resolution and press ENTER button to confirm ① ② ③ ① 10M resolution ② 14M resolution ③...
- Page 24 Turn on the power button, enter USB mode, it acts as a mass storage device. 8. Conformity The Manufacturer hereby declares that the CE marking was applied to the Rollei PDF-S 340 in accordance with the basic requirements and other relevant provisions of the following CE Directives: 2011/65/EC RoHs Directive 2004/108/EC Low Voltage Directive 1999/5/EG R&TTE Directive...
- Page 25 9. Technical Specifications Lens : 2G3P F/NO=3.98 f=5.22 Film Range:51.5mm F/NO=3.4 f=5.12 Photo Range: 170mm Sensor : 14 mega pixels CMOS sensor LCD: 2.4 inch LTPS LCD Display External memory: SD/MMC card Exposure : Auto Color balance : Auto Scan high resolution : 22M interpolation resolution Data conversion : 12 bits per color channel...
