H915A
H915A
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the H915A and is the answer not in the manual?

Questions and answers

Related Manuals for BH FITNESS H915A

Summary of Contents for BH FITNESS H915A

  • Page 1 H915A H915A OWNER’S MANUAL...
  • Page 4 Assembly STEP 1 Attach the front (16) and rear feet (12) to the frame using the nuts (8), washer (9) and bolts (10).
  • Page 5 Step 2 The handlebar post already set up when you received. Attach the handlebar post inserting into the head tube of the frame. Adjust the height and then securely tighten the knob (44) in proper position. Adjust the angle of handlebar (21) and then securely tighten the screw (52) Step 3 Insert the seat tower (17) into the frame’s seat...
  • Page 6 Step 5 To adjust the exercising resistance on the complete spinning bike by the brake knob (42) of brake system, and then simply loosen (-) or tighten (+). The flywheel should rotate freely without resistance when you loosen (-) the brake system totally. More experienced riders may wish to increase the overall resistance by tighten (+) the brake system totally.
  • Page 7 Instruction ; Handlebar and seat adjustment. It is important that the handlebar and seat are set at the correct height for your body. Ask your instructor for assistance. Adjusting the handlebar height-Undo the knob that is located where the stem fits into the frame. Slide the handlebar/stem up or down to the required height and retighten the knob.

  • Page 8: Exploded Drawing

    Exploded Drawing...

  • Page 9: Part List

    Part list No. Name No. Name Unit Unit Saddle Handlebar stem end cap Seat slider Crank bolt Seat tower rubber cap Flywheel security nut Seat tower rubber cap cover for flywheel w/bolt Crank arm set SET 36 flywheel adjuster bolt Chain Console Foot tube nut...

  • Page 10: Maintenance Chart

    Maintenance Chart DESCRIPTION Daily Weekly Monthly Quarterly Annually Keep machine clean: Wipe machine down with clean & dry fabric to clear dirt & sweat. Spray with WD40 or similar on the seat post set, handlebar set (Don’t spray on the main frame) Visual check Check security of handle bar post &...

  • Page 11: Exercise Computer

    EXERCISE COMPUTER FUNCTION BUTTON MODE PRESS EACH TIME TO SWITCH FUNCTIONS. IN FOLLOWING ORDER : SCAN>TIME>CAL>DIST>RPM, OR HOLDING PRESS FOR DELETE ALL DATA. RESET HOLDING PRESS FOR DELETE ALL DATA. FUNCTIONS SCAN AUTOMATICALLY SCAN THROUGH EACH MODE IN SEQUENCE EVER 6 SECONDS. TIME ACCUMULATES TOTAL WORKING TIME UP TO 99:59.
  • Page 12 BH Asia Ltd. No. 80, Zhongshan Rd., Daya Dist., Taichung City 42841, Taiwan (R.O.C) Tel: +886 4 2560 9200 Fax: +886 4 2560 9280 Email: info@bhasia.com.tw...
