Accessory Ramp Kit for GearCage Cargo Carriers
Part No. H00680
PRODUCT MANUAL
ASSEMBLY, INSTALLATION, AND OPERATION INSTRUCTIONS
Installation & Safe Use Operation Highlights
Fits GearCage Model Cargo Carriers (Sold Separately)
Rated for 300 lbs of cargo payload.
For More Information & Accessories, Visit our Website - www.LetsGoAero.com
For Technical Support & Product Questions Contact Us at 877-464-2376 or 719- 630-3800
Email: SUPPORT@LETSGOAERO.COM
Copyright© 2017, Lets Go Aero, Inc., All rights reserved.
GC RAMP 110117
PAGE 1 OF 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GearCage Ramp and is the answer not in the manual?

Questions and answers

Summary of Contents for LetsGoAero GearCage Ramp

  • Page 1 Installation & Safe Use Operation Highlights Fits GearCage Model Cargo Carriers (Sold Separately) Rated for 300 lbs of cargo payload. For More Information & Accessories, Visit our Website - www.LetsGoAero.com For Technical Support & Product Questions Contact Us at 877-464-2376 or 719- 630-3800 Email: SUPPORT@LETSGOAERO.COM Copyright©...
  • Page 2: Parts List

    PARTS LIST 27” CROSS TUBE TOOLS NEEDED: 48” SIDE TUBE 4mm ALLEN WRENCH FLAT HEAD SCREWDRIVER PIN NUT 5mm ALLEN WRENCH 10mm SOCKET or WRENCH M6 x 65 BUTTONHEAD BOLT M6 FLAT WASHERS 3/16 ALLEN WRENCH 13mm SOCKET or WRENCH TRANSITION FLAP 5/32 ALLEN WRENCH 1/2in SOCKET or WRENCH...
  • Page 3 STEP 1 Lay out the two (2) Side Tubes [B] and [Figure 1] four (4) Cross Tubes [A] as shown [Figure 1]. NOTE: Each Cross Tube [A] end should align with the holes located on the sides of the Side Tubes [B]. NOTE: The Pull Latches located along the Side Tubes [B] should be parallel Pull Latches...
  • Page 4 STEP 4 TOOL(S): 4mm ALLEN WRENCH & 10mm SOCKET or WRENCH Place one (1) Floor Panel [G] starting on the edge of the Ramp assembly aligning the mounting holes [Figure 6]. Secure the Panel to the assembly using three (3) M6 x 40 ButtonHead Bolts [H], six (6) M6 Flat Washers [E], and three (3) M6 Nylock Nuts [J] in the mounting holes located closest to the Transition Flap [F], as shown.
  • Page 5 STEP 6 TOOL(S): 4mm ALLEN WRENCH, 10mm SOCKET or WRENCH, 5mm ALLEN WRENCH & 13mm SOCKET or WRENCH Repeat STEPS 4 & 5 with the 2nd Floor [Figure 8] Panel on the opposite side of the Ramp leaving room in the center for the final Floor Panel [G] [Figure 8].
  • Page 6 STEP 8 TOOL(S): 4mm ALLEN WRENCH & 10mm SOCKET or WRENCH Working from the bottom of the Ramp assembly, secure the Floor Panel using six (6) M6 x 16 Buttonhead Bolts [P], twelve (12) M6 Washers [S], and six (6) M6 Nylock Nuts [J] as shown. [Figure 10] [Figure 10] STEP 9 TOOL(S): 5/32 ALLEN WRENCH &...
  • Page 7 STEP 10 TOOL(S): 4mm ALLEN WRENCH & FLAT HEAD SCREWDRIVER Install one (1) Latch Keeper [Q] onto each open end of the GearCage Side Rail by threading one (1) M6 GearCage x 40 Button Head Bolt [H] with one (1) M6 Washer Pin Nut [S] through Latch Keeper and into the existing Pin Nut located inside the GearCage carrier Side Rail.
  • Page 8: Ramp Operation

    RAMP OPERATION [Figure 16] Pull Latches [Figure 15] TO SECURE RAMP UPRIGHT: Lift and pivot the ramp upright until the Pull Latches located on the Side Tubes engage into the “keyholes” of the Latch Keepers. [Figure 15 & 16] NOTE: Pull Latches may be offset and need to adjusted in order to operate properly. TO FOLD DOWN RAMP: Simultaneously pull the Latch Pulls toward the center of the Ramp until each Latch Keeper releases.
  • Page 9: Warranty And Registration

    Never exceed your vehicle and hitch receiver’s tongue weight specification. Weight and Load Parameters The GearCage Ramp is rated for up to 300 lbs of cargo payload weight. The Ramp weighs 35lbs. For your total weight in hitch, add the ramp and carrier weights.
