Slide-Out Enclosed Cargo Carrier System
Set Item Product
PRODUCT MANUAL
ASSEMBLY, INSTALLATION, AND OPERATION INSTRUCTIONS:
Installation & Safe Use Operation Highlights
Fits 2" size receiver hitches.
Rated for 300 lbs of cargo payload. 160 lbs empty weight.
Class II minimum tow rating required; Class III recommended.
For More Information & Accessories, Visit our Website - www.LetsGoAero.com
For Technical Support & Product Questions Contact Us at 877-464-2376 or 719- 630-3800
Email: SUPPORT@LETSGOAERO.COM
PAGE 1 OF 7
BBOXManual-081717Rev
Advertisement
Table of Contents
Related Manuals for LetsGoAero BIGBOX
Summary of Contents for LetsGoAero BIGBOX
- Page 1 Rated for 300 lbs of cargo payload. 160 lbs empty weight. Class II minimum tow rating required; Class III recommended. For More Information & Accessories, Visit our Website - www.LetsGoAero.com For Technical Support & Product Questions Contact Us at 877-464-2376 or 719- 630-3800 Email: SUPPORT@LETSGOAERO.COM...
-
Page 2: Parts List
PARTS LIST REQUIRED TOOLS: 5/32” ALLEN WRENCH, RUBBER MALLET, 3/8” WRENCH, 7/16” WRENCHES, PHILLIPS SCREWDRIVER, DRILL AND DRILL BITS, HAMMER, CENTER PUNCH, FELT TIP PEN, ALCOHOL AND CLOTH QTY. DESCRIPTION QTY. DESCRIPTION COVER SELF-TAPPING HEX HEAD SCREW .75” BULK HEAD HEX HEAD SCREW, 1/4-20 x 1.5”... - Page 3 STEP 1 Compress one Spring Nut [BB] within the FlatPipe Spine [AA] end as shown. [Figure 1] The Spring Nut may be installed between either the first or the second mounting hole (user choice) [Figure 1]. NOTE: The FlatPipe Spine [AA] end (called the “Shank”) contains two (2) mounting holes.
- Page 4 STEP 5 Slide the GearCage Rack [KK] all the way back onto the Flat Pipe Spine [AA]. STEP 6 Slide the Large Plastic Washer [JJ] onto the Hand-Tighten Silent Hitch Pin [HH]. In the same manor as Step 2, insert and thread the Hand-Tighten Silent Hitch Pin [HH] with the Plastic Washer [JJ] through the Flat Pipe [AA] and GearCage Rack [KK] and internal Spring Nut [BB].
- Page 5 STEP 8 TOOL: 5/32” HEX WRENCH Insert the bulk head [C] into the groove near the edge of the cover [A]. Insert pin nut [D] making sure the slot end is towards the outside. Insert and tighten joint con- nector bolt [E]. Repeat to attach the remain- ing bulk head to the other side of the cover [A].
- Page 6 STEP 11 TOOLS: DRILL AND 3/16” BIT, 1/8” BIT, 3/8” WRENCH, PHILLIPS SCREWDRIVER, HAMMER, CENTER PUNCH Using existing holes as a guide, drill through the plastic (use 3/16” bit). Attach latch [M] as pictured using two each [H, and J]. Repeat for attachment of other latch.
- Page 7 To learn more about our products and stay informed about useful options for transporting all kinds of gear with your Let’s Go Aero, Inc. carrier, be sure to visit our website: www.LetsGoAero.com Phone: 877-464-2376 or 719-630-3800 Copyright© 2017, Lets Go Aero, Inc., All rights reserved.
