Parts List
Description
V2 Base
NoMotion™ Pin w/ clip
SilentACT™ Locking Pin
2" Nylon Adapter
Wing with Pads
Wire Lock Pin
Double Toggles
Wheel Cradle Assembly
Wheel Cradle
Toggle Balls
Hair Pin Clip
U-Clip
Tool required to tighten
NoMotion™ Hitch Pin: 3/4"
No Tool Required for
SilentACT™ Locking Hitch Pin
Assembly
Step 1: Insert V2 Base Shank into receiver hitch
Insert V2 Base Shank into receiver hitch. Align the pin hole of the
shank with that of the vehicle hitch pin hole. Thread in the NoMotion
Pin, apply clip and tighten with a ¾" suitable tool.
NEW! VALUE-ADDED FEATURE
SilentACT™ Accessory Control Technology - No Motion, No Tool re-
quired device locks rack to hitch. For security and convenience, apply
SilentACT™ locking hitch pin.
On vehicles with a 2" hitch receiver, use the 2" nylon adapter as
shown in the assembly view.
BVR062 1214
Qty
1
1
1
1
2
2
4
4
4
4
4
V
Two-Bike Carrier
2™
U.S. Patent No: D684917; patents pending
Wire Lock Pins
Bike Carrier Shank
Double
Toggles
Part No. BVR062
User Manual
Wheel Cradle
Assembly
Wing with
Pads
NoMotion Pin
2" Nylon
Adapter
Advertisement
Table of Contents
Related Manuals for LetsGoAero V2 Two-Bike Carrier
Summary of Contents for LetsGoAero V2 Two-Bike Carrier
- Page 1 Two-Bike Carrier 2™ Part No. BVR062 User Manual U.S. Patent No: D684917; patents pending Parts List Description V2 Base Wheel Cradle NoMotion™ Pin w/ clip Assembly SilentACT™ Locking Pin 2” Nylon Adapter Wing with Pads Wing with Wire Lock Pin Pads Double Toggles Wire Lock Pins...
- Page 2 Step 2: Assemble Wings Step 3: Attach Wheel Cradle Assembly Slide Wings into the Base pockets and secure the Determine the approximate center-to-center distance Wings to the Base with the Wire Lock Pins. between the hubs of the bike wheels and attach the wheel cradles to the Wings with the Hair Pin Clips to match this distance.
