Summary of Contents for OAKWORKS Marina

  • Page 1 I N S T R U C T I O N M A N U A L ® Oakworks Marina...
  • Page 2 , Inc. for incidental or consequential damages in connection with or arising out of the furnishing, Oakworks ® is a registered performance, or use of this trademark of Oakworks ® , Inc. document and the program material which it describes.
  • Page 3: Table Of Contents

    Section II: Directions for Use pg 4 Leveling Instructions ......... Section II: Directions for Use .............. pg 5 Moving the Table pg 6 Marina™ Hand Control ............. pg 7 Important Safety Note ............Table Operation: ..........pg 7 Battery pg 10 Drape &...
  • Page 4: Symbol Identification

    SYMBOL IDENTIFICATION SYMBOL IDENTIFICATION SYMBOL (used on product and labels) This symbol, when used in documentation on this product, represents a caution. Be sure to read and comply with all precautions and warnings. This symbol, when used in documentation on this product, indicates danger and warns against an electrical shock hazard.
  • Page 5: Warnings And Important Safety Instructions

    WARNINGS / SAFETY INSTRUCTION WARNINGS & IMPORTANT SAFETY INSTRUCTIONS IMPORTANT READ AND SAVE THESE INSTRUCTIONS WARNINGS & IMPORTANT SAFETY INSTRUCTIONS Improper use of this device can cause injury. Be sure to read all operating instructions prior to use to prevent injury to operator or client. Electrical Shock Hazard.
  • Page 6 The table weighs as much as 225 lbs. Do Not lift or move the unit without CAUTION using proper safely procedures or equipment. DO NOT turn the Marina™ on its side for any reason. To do so could cause damage to the base and will void the warranty.
  • Page 7: Introduction

    ™ The Marina raises and lowers your clients to the optimal working Children must be supervised height easily. The variety of height positions align the Marina ™ when around this equipment by a responsible adult. so your client’s body is at the optimum level for any number of treatments.
  • Page 8: Marina

    PRODUCT DESCRIPTION • Marina™ PRODUCT DESCRIPTION Total Lifting Capacity: ™ Marina 400 lbs. Maximum Working Load • Quiet height adjustments with the touch of a button accommodates practitioners and estheticians of all sizes • The maintenance-free whisper quiet motor powers the electric lift feature •...
  • Page 9 PRODUCT DESCRIPTION • Marina™ PRODUCT DESCRIPTION Water Bag Fitted Table Upholstered Top Drape (1) ™ Marina Accessory Outlets (4) Lo-voltage Vertical Battery Controlled Lift Column (1) Shown here with optional Draining Gutter and draining tube Leveling Feet (4) Ta b le S p ec s* •...
  • Page 10: Section Ii: Directions For Use

    DIRECTIONS FOR USE • Leveling Feet The Marina™ comes completely assembled and ready to use. Be sure to charge the battery for 4 hours prior to use. Arrange the control cords so that they will not create a tripping hazard.
  • Page 11: Section Ii: Directions For Use

    IMPORTANT Mo ving the T a b l e Be sure to read all cautions, The Marina ™ weighs approximately 225 lbs. You will need 4 people work- warnings and instructions given ing together if it is necessary to move the table.
  • Page 12: Marina™ Hand Control

    •Adjusting the Table Height using the Hand Control DIRECTIONS FOR USE • Hand Control ADJUSTING THE HEIGHT OF THE TABLE: The Oakworks® Marina™ comes complete with a hand control to operate the height of the table with ease. IMPORTANT Hand Control: 2 positioning Buttons...
  • Page 13: Important Safety Note

    DIRECTIONS FOR USE • Important Safety Note • Table Operation DIRECTIONS FOR USE I MP OR T A N T S A FE T Y N OT E IMPORTANT The area under the top is not designed for storage or as an area to hold accessories while with a client.
  • Page 14 DIRECTIONS FOR USE • Battery Use DIRECTIONS FOR USE • Battery TABLE OPERATION: (CONT) To Turn the Control Box ON: Turn the red ‘Emergency’ button on the control box, found under the table, in a clockwise direction. IMPORTANT CAUTION Children must always be supervised when around this equipment by a responsible adult.
  • Page 15 DIRECTIONS FOR USE • Battery Use DIRECTIONS FOR USE • Battery TABLE OPERATION: (CONT) Pull the battery out and place it firmly onto the charger bracket. Plug in the charger to begin charging the battery. IMPORTANT Be sure to read all cautions, warnings and instructions given in the manual to prevent injury to both operator and client.
  • Page 16: Drape & Hot Water Bag

    The • Acessory Option: Marina™ has outlets at the head of the table for a variety of uses and outlets at the other end that work as well for additional procedures.
  • Page 17 DIRECTIONS FOR USE • QuickLock Face Rest DIRECTIONS FOR USE • Accessory Option: QUICKLOCK™ FACE REST: (CONT) QuickLock™ Face Rest: (cont) Attaching the QuickLock™ Face Rest / Head & Foot End Outlets: When attaching the QuickLock™ Face Rest to the foot end by using the provided outlets, just slide the frame dowels into the outlets being sure to keep the 1st cam lock within 3”...
  • Page 18 DIRECTIONS FOR USE •QuickLock™ Face Rest DIRECTIONS FOR USE • Accessory Option: QUICKLOCK™ FACE REST: (CONT) QuickLock™ Face Rest Tips for Great Positioning using the QuickLock™ Face Rest: (cont) IMPORTANT • The face pad is flexible so that you can bring the open ends together or spread them apart to achieve the most comfortable Be sure to read all cautions, support for any size face.
  • Page 19: •Optional Gutter Operation

    This could cause the drain to clog and interfere with the free flow of the drain For most treatments the Oakworks® AquaDuct™ drain system will tube. collect and flow the treatment solution into the table drain tubing with ease.
  • Page 20: Section Vi: Care & Cleaning

    ™ BATTERY: Marina In order to maintain the quality and ensure the life of the Marina™, here are some preventative steps that can be taken to protect the battery. • The charger must be used in a dry environment. • Normal use of the lift function of the table is a 10% duty cycle (i.e.
  • Page 21 HOW TO CARE FOR YOUR UPHOLSTERY: ™ In order to maintain the quality and ensure the life of the Marina model of your choice, here are some preventative steps that can be taken to protect the upholstery on the table and accessories.
  • Page 22: Section V: Troubleshooting

    The table weighs as much as 225 lbs. Do Not lift or move the unit without using proper safety procedures or equipment. DO NOT turn the Marina™ on its side for any reason. To do so could Level Indicator - OK Level Indicator - Low cause damage to the base and will void the warranty.
  • Page 23: Section Vii Table Specifications

    SPECIFICATIONS • Marina™ SPECIFICATIONS Marina ™ Model No: MARC ELECTRICAL SPECS: Designed for: North America Europe/United Kingdom Japan/Korea Battery Charger Electrical Service 120 V/60 Hz 220 V/50 Hz 100 V/5-60 Hz Current Draw .7 A .4 A .8 A Electric Shock...
  • Page 24: Section Viii: Product Identification

    PRODUCT IDENTIFICATION • Power Lead Plugs PRODUCT IDENTIFICATION POWER LEAD PLUGS Part #: Voltage (AC) Power Cord Plug Oakworks ® 5097-1 120v 60 Hz 3 prong grounded hospital grade; North America 5097-3 220v 50 Hz Continental Plug; Europe 5097-4 220v 50 Hz Swiss plug;...
  • Page 25: Section Ix: List Of Parts

    LIST OF PARTS • Marina™ LIST OF PARTS Part No. Description Marina™ Marina™: 6978 Column DL2 (1) •Model #: MARC 7014 Control Box (1) 6959 Hand Control /2 buttons (1) 6958 Charger for Battery System (1) 7013 Battery (1) 6979...
  • Page 26: Section X: Warranty

    - MODEL # MARC Please refer to www.oakworks.com for current warranty information. All warranties are limited to factory-provided replacement parts, factory repair or replacement, at the discretion of Oakworks ® Oakworks only covers parts and labor on field repair of stationary ®...
