- Page 1 I N S T R U C T I O N M A N U A L ® AKWORKS Clodagh Model...
- Page 2 © 2005 O ® , Inc. AKWORKS Notice The information contained in this document is subject to change Manual Part # MMINXX0122-CLO without notice and should not Edition 1, English Aug 2007 be construed as a commitment by ® , Inc. AKWORKS All rights are reserved.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS Symbol Identification ................pg iii Warnings ....................pg iv Grounding Instructions ................. pg vi Introduction ..................pg 1 Section I: Product Description & Photo Celesta Gemini ™ pg 2 ..........LODAGH ODEL Section II: Installation Leveling Instructions ............ -
Page 4: Symbol Identification
SYMBOL IDENTIFICATION • How to Care for Your Upholster y SYMBOL IDENTIFICATION... - Page 5 SYMBOL IDENTIFICATION SYMBOL IDENTIFICATION SYMBOL IDENTIFICATION This symbol, when used in documentation on this product, represents a caution. Be sure to read and comply with all precautions and warnings. This symbol, when used in documentation on this product, indicates danger and warns against an electrical shock hazard.
- Page 6 WARNINGS & IMPORTANT SAFETY INSTRUCTIONS • How to Care for Your Upholster y WARNINGS & IMPOR TANT SAFETY INSTR UCTIONS READ AND IMPOR TANT SAFETY INSTR UCTIONS SAVE THESE INSTRUCTIONS Improper use of this device can cause injury. Be sure to read all operating instructions prior to use to prevent injury to operator or client.
-
Page 7: Warnings
WARNINGS WARNINGS & IMPORTANT SAFETY INSTRUCTIONS READ AND IMPOR TANT SAFETY INSTR UCTIONS (CONT.) SAVE THESE INSTRUCTIONS This product is equipped with an interior accessory outlet. The total WARNING electrical load of equipment plugged into this set of outlets is not to exceed 840 watts. -
Page 8: Grounding Instructions
WARNINGS & IMPORTANT SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS WARNINGS & IMPORTANT SAFETY INSTRUCTIONS READ AND IMPOR TANT SAFETY INSTR UCTIONS (CONT.) SAVE THESE INSTRUCTIONS • To remove the accessory from the cabinet: Turn the accessory controls WARNING to the ‘off’ position and then disconnect the unit from the interior power source by removing the plug from the outlet. -
Page 9: Introduction
INTRODUCTION • elesta emini ™ INTR ODUCTION elesta emini ™ Clodagh Model ® offers a variety of positioning capabilities for elesta emini ™ AKWORKS massage therapists and skincare professionals of all specialties. On this multi- functional professional model table the practitioner can perform numer- ous protocols with ease and comfort. -
Page 10: Clodagh Model
PRODUCT DESCRIPTION • elesta emini ™ PRODUCT DESCRIPTION elesta emini ™ MODEL CLODAGH Total Lifting Capacity: MODEL #: 625 lbs. Maximum Working Load GMCLMP312572ACUTVN • Quiet height adjustments with the touch of a button accommodates practitioners and estheticians of all sizes •... - Page 11 PRODUCT DESCRIPTION • elesta emini ™ PRODUCT DESCRIPTION QuickLock™ Face Rest Upholstered Self Adjusting elesta emini ™ Remova ble Ar m Rests (2) Access MODEL CLODAGH Design Top Leg Rest Back Rest MODEL # GMCL Hand Control (1) Seat Sliding Ca binet door s (2 - access both sides) Exter ior...
-
Page 12: Section Ii: Installation
INSTALLATION • Leveling Instr uctions INSTALLATION elesta emini ™ comes completely assembled and ready to use. Plug the • Leveling Feet cord into a functioning outlet that is rated for the table. Arrange the power cord and control cords so that they will not create a tripping hazard. -
Page 13: Section Iii: Directions For Use
DIRECTIONS FOR USE • Adjusting Height and Tilt Angle of the using the Foot Control elesta emini ™ DIRECTIONS FOR USE ADJUSTING HEIGHT OF THE TABLE: elesta emini ™ The O ® elesta emini ™ comes complete with a multifunctional AKWORKS •... - Page 14 DIRECTIONS FOR USE • Adjusting Height and Top Positions of the using the Hand Control elesta emini ™ DIRECTIONS FOR USE elesta emini ™ elesta emini ™ HAND CONTR OL OPERATIONS • • Hand Control When operating the controls be elesta emini ™...
- Page 15 DIRECTIONS FOR USE • Adjusting Height and Top Positions of the using the Hand Control elesta emini ™ DIRECTIONS FOR USE elesta emini ™ HAND CONTR OL OPERATIONS • elesta emini ™ • Hand Control CAUTION When operating the controls and elesta emini ™...
- Page 16 DIRECTIONS FOR USE • Adjusting Height and Top Positions of the using the Hand Control elesta emini ™ elesta emini ™ elesta emini ™ HAND CONTR OL OPERATIONS • • Hand Control Pre-set Positions CAUTION When operating the controls and elesta emini ™...
-
Page 17: Under-Table Cabinet
DIRECTIONS FOR USE • Impor tant Safety Note/ elesta emini ™ • Under-Ta ble Ca binet elesta emini ™ DIRECTIONS FOR USE IMPORTANT elesta emini ™ IMPOR TANT SAFETY NOTE • CAUTION The cabinet hood area under the backrest top is not designed for storage or as an area to hold accessories while with a client. - Page 18 DIRECTIONS FOR USE • Under-Ta ble Ca binet elesta emini ™ DIRECTIONS FOR USE • Under-Table UNDER-TABLE CABINET Cabinet (cont) To Access the Storage in the Under Table Cabinet: (cont) of the table, slide independently with slight pressure on the handles found in the top of each door.
-
Page 19: Side Arm Rests
DIRECTIONS FOR USE • Use & Adjustment of the elesta emini ™ Ar m Rests DIRECTIONS FOR USE • Side Arm Rests SIDE ARMRESTS: Though the arm rests adjust automatically to remain parallel to the floor in any position, there will still be times when you will need to IMPORTANT move an arm rest out of the way or remove them altogether. - Page 20 DIRECTIONS FOR USE • Use & Adjustment of the Ar m Rests elesta emini ™ DIRECTIONS FOR USE SIDE ARM RESTS: • Side Arm Rests C O N T (cont.) To remove one or both arm rests just take hold of the base of the arm rest at the metal frame and somewhere on the cushion.
-
Page 21: Quicklock Face Rest
DIRECTIONS FOR USE • QuickLock ™ Face Rest DIRECTIONS FOR USE QuickLock ™ FACE REST: • Accessory Option: QuickLock ™ Face Rest Double articulating action provides nearly limitless positioning options with the QuickLock ™ Face Rest.The adjustable pad takes pressure off sensitive facial areas while providing superb support. - Page 22 DIRECTIONS FOR USE • QuickLock™ Face Rest DIRECTIONS FOR USE Attaching the QuickLock ™ Face Rest / Foot End Outlets: • Accessory Option: When attaching the QuickLock ™ Face Rest to the foot end by using the QuickLock ™ provided outlets, just slide the frame dowels into the outlets being sure to Face Rest (cont.) keep the 1 st cam lock within 3"...
-
Page 23: Accessory Option: Table Extender
DIRECTIONS FOR USE • Accessor y Option: Ta ble Extender • Moving the elesta emini ™ DIRECTIONS FOR USE • Accessory Option: Table Extender Be sure to read all cautions, warnings and instructions given in the manual to prevent injury to both operator Outlets and client. -
Page 24: Section Iv: Troubleshooting
TROUBLESHOOTING • If will not Change Height or Position elesta emini ™ • Hand Control Replacement TROUBLESHOOTING ™ F THE WILL NOT CHANGE HEIGHT OR POSITION ELESTA EMINI • Controls • Check the outlet to be sure that it has power and that the power IMPORTANT cable is plugged in. - Page 25 TROUBLESHOOTING • Hand Control Replacement Instr uctions TR OUBLESHOOTING 4. To access the control box to disconnect the hand control you must first remove the control box mounting bracket from the underside of • Hand Control the cabinet (head end) by unscrewing the four knobs that hold the (cont) bracket in place.
- Page 26 TROUBLESHOOTING • Hand Control Replacement Instr uctions TR OUBLESHOOTING • Hand Control 7. Take the new hand control and thread the straight section of cord closest to the plug into the slit of the plastic cord restraint. The (cont) cords for both the hand control and the foot control will fit in to this slit.
-
Page 27: Foot Control Replacement Instructions
TROUBLESHOOTING • Foot Control Replacement Instr uctions TR OUBLESHOOTING FOOT CONTROL REPLACEMENT INSTRUCTIONS • Foot Control Replacement of the Foot Control may be necessary if the control does IMPORTANT not actuate the functions of raising or lowering the elesta emini ™... - Page 28 TROUBLESHOOTING • Foot Control Replacement Instr uctions TR OUBLESHOOTING • Foot Control Follow the cord for the foot control back to the place where it connects to the control box. Press down on the cord connector tab and (cont) unplug the foot control. IMPORTANT CAUTION The table weighs as much...
- Page 29 TROUBLESHOOTING • Foot Control Replacement Instr uctions TR OUBLESHOOTING 8. Plug the new foot control into the control box bracket at the • Foot Control same connection where the inoperable unit had been. (cont) 9. Carefully lift the control box, mounting bracket and excess cords back up into the cabinet floor, being careful to keep all the excess out of the way of the control box opening.
-
Page 30: Section V: Care & Cleaning
CARE & CLEANING • How to Care for Your Upholster y CARE & CLEANING HOW TO CARE FOR YOUR UPHOLSTERY: • Upholstery In order to maintain the quality and ensure the life of the elesta emini ™ here are some preventative steps that can be taken to protect the upholstery on the chair and accessories. -
Page 31: Section Vi: Product Identification
PRODUCT IDENTIFICATION • Power Lead Plugs PR ODUCT IDENTIFICATION POWER LEAD PLUGS • Plugs Part #: Voltage (ACE) Power Cord Plug ® AKWORKS 7791 120v 60 Hz 3 prong grounded These part numbers hospital grade; are for identification North America only;... -
Page 32: Section Vii: Table Specifications
SPECIFICATIONS SPECIFICATIONS elesta emini ™ Model Clodagh; Model No. GMCL North America Europe/Switzerland United Kingdom Australia Japan/Korea Designed For: Voltage/Current 120 VAC/ 20 amps 220 VAC/ 10 amps 220 VAC/ 10 amps 220 VAC/ 10 amps 100 VAC/ 20 amps Service Available Input Frequency 60 Hz... -
Page 33: Section Viii: List Of Parts
LIST OF PARTS LIST OF PAR TS FLUOR OSCOPY TABLE elesta emini ™ Part No. Description MODEL CLODAGH 2378 Column DL1(4) 2379 Cable, Motor (1) MODEL #GMCL 7324-1 Control Box, Master (1) 7324-2 Control Box, Master / EU (1) 7324-3 Control Box, Master / Japan (1) 7328-1 Control Box, Slave (1) -
Page 34: Section Ix: Warranty
WARRANTY STATEMENT • How to Care for Your Upholster y WARRANTY STATEMENT elesta emini ™ Model Clodagh; Model No. GMCLMP312572ACUTVN RAME PHOLSTERY LECTRICAL ETURN EPLACEMENT NDERSTRUCTURE ADDING OMPONENTS HIPPING HIPPING Limited Lifetime Warranty — Included in 5 years 2 years original owner;... -
Page 35: Contact Information
CONTACT INFORMATION: ® Inc. AKWORKS 923 East Wellspring Road New Freedom, PA 17349 Toll Free (USA only): 800-916-4613 Phone: 717-235-6807 Toll Free FAX (USA only): 877-562-4787 FAX: 717-235-6798 www.oakworks .com... - Page 36 INSTRUCTION MANUAL ® MASSAGE TABLES 64CA Manual Part # MMMLXX0122-CLO Edition 1, English Aug 2007 Printed in U.S.A.
