Invacare DOLOMITE JAZZ Instructions For Service

Service instructions

FUTURA, LEGACY, SYMPHONY, MAXI, MAXI +
Instructions for service on DOLOMITE Jazz rollator
The following check-ups and controls are to be done when maintaining the Dolomite Jazz rollator
WHEEL/FORKS
Examine that/if:
1
The wheel spins easily.
2
The tread is not damaged.
The wheel bolts are properly tight-
3
ened.
The screws on rear forks are tight-
4
ened.
The front fork is properly assem-
5
bled into the frame.
6
The front fork has no damages.
The rear fork has no mechanical
7
damages.
All wheels have contact with plane
8
surface.
BRAKE
Examine that/if:
1
The brake flap is not worn out.
2
The brake flap returns after braking. Change the brake flap or wire and cover.
The brake wire moves easily in the
3
wire cover.
4
Full braking action is obtained.
End parts on wire-covers are not
5
damaged.
Brake handle/housing is not
6
damaged.
To do:
Change the wheel and locking nut.
Tighten the bolts, (use permanent locking
glue if locking nut is not available).
Tighten the bolts, (use permanent locking
glue if locking nut is not available).
Tighten the screws.
Tighten the front fork in the frame with
60 Nm.
Change the fork. Tighten the front fork in
the frame with 60 Nm.
Change the fork.
Adjust the rear wheel by moving rear fork
up or down.
To do:
Exchange brake flap
Change wire and, if needed, cover.
Adjust the braking action with the wire
adjusting screws.
Change the wire cover.
Change the brake handle.
Comments:
Use new locking nut!
Use new locking nut!
Comments:
(spring can be jammed)
The distance between the
brake flap and the wheel
must not exceed the follow-
ing meassurements:
Futura with DABS II fork:
2 mm
Legacy with DABS fork:
2,5 mm
Legacy with DABS II fork:
4 mm
Art no 1542536-1
OK
OK
2011-04-26
1
