• The toy is not to be connected to more than the recommended number of power
supplies.
• Do not dispose of batteries in fire.

AC Adaptor

AC Adaptor
®
• Use a VTech
9V
with equivalent specification.
• Make sure the unit is turned OFF.
• Plug the power jack into the 9V DC socket at the back of the unit.
• Plug the AC adaptor into a wall socket.
NOTE:
The use of an adaptor will override the batteries. When the toy is not going to
be in use for an extended period of time, unplug the adaptor.

standard Guidelines for Adaptor toys

standard Guidelines for Adaptor toys
• The toy is not intended for use by children under 3 years old.
• Only use the recommended adaptor with the toy.
• The transformer is not a toy.
• Never clean a plugged-in toy with liquid.
• Never use more than one adaptor.
• Do not leave the toy plugged-in for extended periods of time.
Connecting a tV Connecting a tV
NOTE: Before you connect the V.Smile
TV, check to make sure that the unit is working. Check to see that the adaptor
is connected correctly, or that the batteries are installed correctly. If the batteries
are not installed correctly, the V.Smile
will not function and damage to the unit could result. Make sure that your TV
and the unit are turned OFF before you begin making connections.
Connect the V.Smile
plugging the colored cables on the unit into the matching color video and audio input
jacks on your TV set.
yellow White
300mA
l
®
Active learning System to your TV or monitor by
Motion
tm
For TVs with stereo audio inputs:
- Connect the yellow plug on the V.Smile
the yellow video input terminal on your TV.
- Connect the white plug on the V.Smile
white audio input terminal on your TV.
AC/DC adaptor or a standard AC/DC adaptor
®
Active learning System to a
Motion
tm
®
Motion tm
Active learning System
®
cable to
Motion
®
cable to the
Motion
