BATTERY INSTALLATION:

1. Make sure the unit is turned OFF.
2. locate the battery cover on the back of Voyager and open it.
3. Insert 4 new C (UM-2/LR14) batteries, as illustrated.
(The use of alkaline batteries is recommended for
maximum performance.)
4. Close the battery cover.
STANDARD FOR BATTERY TOYS
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the toy before being charged (if
removable).
• Rechargeable batteries are only to be charged under adult supervision (if
removable).
• Different types of batteries or new and used batteries are not to be mixed.
• Only batteries of the same or equivalent type as recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the toy.
• The supply terminals are not to be short-circuited.
• The toy is not to be connected to more than recommended number of power
supplies.
• Do not dispose of battery in fire.
NOTE: If the unit suddenly stops working or the sound becomes weak, turn the unit
off for 15 seconds, then turn it back on. If the problem persists it may be
caused by weak batteries. Please install a new set of batteries and try the
unit again.
AC ADAPTOR
®
Use VTech or any standard adaptor complying with EN61558 DC 9V
AC centre - positive adaptor.
CONNECTION:
1. Make sure the unit is OFF.
2. Locate the adaptor jack on the right side of the unit.
3. Insert the adaptor plug into the unit's adaptor jack.
4. Plug the adaptor into the unit's adaptor jack
5. Turn the unit ON.
3
300mA
