Title
Models
Document
Version
Revision date
Expected duration
Description
To maintain your Leapfrog Bolt PRO correctly and keep it running smoothly we recommend the
following maintenance work periodically.
Before doing any maintenance activity make sure the machine is completely turned off using the switch
on the back of the machine. Ensure the machine is completely cooled down by waiting 30 minutes after
the last use.
Remember to use protective gloves, glasses, and clothing for each of these activities.
Maintenance Schedule
Bolt PRO
Maintenance Manual
1.5
03-08-2018
-
1
Advertisement
Related Manuals for LeapFrog Bolt PRO
Summary of Contents for LeapFrog Bolt PRO
- Page 1 03-08-2018 Expected duration Description To maintain your Leapfrog Bolt PRO correctly and keep it running smoothly we recommend the following maintenance work periodically. Before doing any maintenance activity make sure the machine is completely turned off using the switch on the back of the machine. Ensure the machine is completely cooled down by waiting 30 minutes after the last use.
- Page 2 Main body Cleaning and Inspection Clean machine interior and surroundings. Before each print. Clean the motherboard and power supply unit Every 500 working hours. with compressed air.
- Page 3 HEPA Filter Install the HEPA carbon filter in the machine. Before each print. Store the HEPA carbon filter in an airtight box. After each print. Replace the HEPA carbon filter. Every 6 months.
- Page 4 Lubricating moving components Ensure X, Y, and Z axes are clean from Before each print. material remains and dust. Lubricate X-axis Shafts using sewing Every 500 working hours. machine oil. Lubricate Y-axis Rails using HIWIN G05 Every 500 working hours. Grease.
- Page 5 Belts Tensioning and Inspection Inspect the tension on X-axis belts (L+R). Every 700 working hours. Inspect the tension on Y-axis belts (L+R). Every 700 working hours. Inspect the tension on Z-axis Belt (Spindle). Every 700 working hours. Inspect the tension on Z-axis Belt (Motor). Every 700 working hours.
- Page 6 Clean the bed. Before each print. Calibrate bed. Every 200 working hours.
- Page 7 Printhead Check both axial fans are working. Every 200 working hours. Remove any material debris on the extruder Before each print. including the nozzle. Inspecte the hot-end thumbscrew is properly Every 100 working hours. tightened. Filament pressure thumbscrew. Always adjust accordingly before inserting new filament.
- Page 8 Wiper Remove any material debris from the wiper Before each print. blade. Calibrate the wiper blades. Every 100 working hours or when changing the hot end. The wiper blade should be as close to the (clean) nozzle as possible without touching it.
