3) Remove the Battery
Pull the plastic strap on the battery, and then remove it.
4) Insert SIM Card
Insert the SIM card (with its gold contacts facing down and cut-off
corner facing inside) all the way into the SIM card slot.
Note: Please ensure your device is powered off before swapping SIM
card.
Note: Don't remove the battery for more than 30 seconds in hot swap
mode or press the battery detector to avoid shutdown.
5) Insert Micro SD Card
Open the SD card holder by pushing the metal cover backward
and lift it. Put the Micro SD card into the socket, close the metal
cover, and push forward till it locked.
6) Put back the Battery
Reinsert the battery by latching the bottom first and then put it down.
7) Check the Sealing Security.
Hot swap battery
If your device has the hot swap feature, you can swap batteries
without powering off your device.
Note: When hot swapping the battery the system will enter suspend
mode.
Note: Don't remove the battery for more than 30 seconds in hot swap
mode or press the battery detector to avoid shutdown.
To scan barcode
1) Tear off protective film from the barcode.
2) Press power button located on the side and swipe up from bottom
to unlock the screen.
3) Open Search application or other which can edit text.
4) Press button located on the side.
5) Scan the following barcode to check if your reader is working properly.
Result will be displayed in Search application.
Code-39
Optimum scanning
To change scanning settings
To change scanning settings
1) Open WDC application.
2) In Barcode Settings tap Trigger Settings.
3) Choose scan type and read time options.
TRIGGER MODE OPTIONS
Auto Scan – auto-scanning once the user leaves the WDC application.
Multiple Scan – continuously scanning and reading multiple codes
within the read time duration (2-9 sec) after pressing button.
Continuing Scan (Default) – scanning only the single code within the
read time duration (2-9 sec) after pressing button.
To change the symbologies of barcode
1) Open WDC application.
2) Tap Barcode Setting.
3) Tap Barcode Preference.
4) Change the symbologies of barcodes.
To add command with the output of barcode
1) Open WDC application.
2) In Barcode Settings tap Prefix / Suffix.
3) Enter special characters at the beginning (prefix) or end (suffix)
of the scanned barcodes.
4) Tap Set to add to the data.
There's more here.
• Keep your E500 updated, and find the latest PC software,
user manual, online help and more at:
http://www.winmate.com/DownCenter/DownLoadCenter.asp?Do
wnType=2021
• Find more accessories for your E500 at:
http://www.winmate.com/TabletPC/E500-Series.asp?showblock=
Accessories
E500 Series PDA
Quick Start Guide
v1.3
